Bryant CRS15 Straight Blade Receptacle 15A 125V

Product Description

The BRYANT CRS15 is a 15A 125V duplex receptacle designed for commercial applications. This straight blade receptacle features sturdy construction with a wrap-around galvanized steel strap and thread-cleaning, captive mounting screws. It is suitable for standard installations requiring electrical performance and durability.

• Self-Grounding Staple
• Easy Access Break-Off Tab for 2-Circuit Wiring
• Double-Wipe Ground Contact

Product Highlights

Commercial grade receptacle with self-grounding and robust construction for reliable power connections.

Product Information

Standard Information

• Brand: BRYANT
• Manufacturer Part Number: CRS15
• Country of Origin: China

Technical Specifications

• Approval: UL 498, CSA C22.2, NOM
• Configuration: NEMA 5-15R
• Constructional Feature: Impact Resistant
• Grade: Commercial, Specification
• Ground Type: Self-Grounding
• Manufacturer Name: Bryant
• Material: Nylon (Body), Steel (Yoke)
• Number Of Poles: 2
• Number Of Wires: 3
• Product UPC: 781786161009
• Type: Smooth Face Duplex
• Wiring: Side
• Application: Commercial Specification Grade
• Catalog Number: CRS15
• Color: Brown
• Environmental Conditions: Indoor Dry Unless Protected By Additional Means
• EU RoHS Indicator: Yes
• Item Type: Traditional Duplex Smooth Face
• Material - Mounting Hardware: Screw Mounting
• OEM Brand Name: Hubbell Bryant
• Series: Commercial
• Style: Smooth Face
• Duplex Receptacle: Duplex Receptacle
• UPC: 781786161009
• Amperage Rating: 15 A
• Connectivity: Side Wired Only
• Current / Amperage Rating: 15 A
• Current Rating: 15 A
• Phase: Single Phase
• Voltage Rating: 125V AC
• Voltage Rating Description: 125 V
• Wattage: 1875
• Wire Size: #14 AWG to #12 AWG
• Nema Rating: 5-15R
• Standards - RoHS Compliance Status: CM
• Brand: BRYANT
• AFCI: No
• Connection Orientation: Straight
• Contact Material: Brass
• Cover Type: No
• For Location: Indoor
• GFCI: No
• Federal Specification: Federal Specification
• Grounding: Grounded
• Horsepower Rating: 1/2 hp
• Housing Color: Brown
• Housing Material: Composite
• IP Rating: IP20
• Includes: Mounting Hardware
• Includes Mounting Hardware: Yes
• Market: Commercial
• Maximum Wire Size: 12 AWG
• Minimum Wire Size: 14 AWG
• Mount Hole Center-to-Center Height: 4.1 in
• Mount Type: Flush
• Mounting Location: Outlet Box
• NEMA Receptacle Configuration: 5-15R
• Number of Gangs: 1
• Number of Outlets: 2
• Polarized: Yes
• Receptacle Type: Duplex
• Special Resistance: Impact Resistant
• Standards: CSA Certified; Federal Specification; UL Listed
• Surge Protection: No
• Wire Connection Type: Screw Terminals
• Wiring Method: Side
• UNSPSC: 39121406
• Type - Plugs and Receptacles: Straight Blade
• Application Environment: Straight Blade
• Amps - Plugs and Receptacles: 15
• Voltage - Plugs and Receptacles: 125VAC
• Tamper Resistant: No
• Weather Resistant - Plugs and Receptacles: No
• Outlet Type - Plugs and Receptacles: Standard Duplex
• Mounting Type - Plugs and Receptacles: Flush
• Color - Plugs and Receptacles: Brown
• Number of Phases: 1
• HP: 0.5
• Corrosion Resistant: No
• Power Indicator: No
• Wiring Method - Plugs and Receptacles: Side
• Manufacturer: Bryant Electric
• Family Series: Bryant Electric Plugs & Receptacles
• Connection Type: Duplex Receptacle
• NEMA Configuration: 5-15R
• Watertight: No
• Isolated Ground: No
• Illuminated: No
• Approvals: CSA, UL
