Bryant BRY5662IG Receptacle 15A 250V Single Pack

Product Description

The BRYANT BRY5662IG is a commercial/industrial grade duplex receptacle. Rated at 15A and 250V, this 2-pole, 3-wire grounding receptacle features a 6-15R NEMA rating and isolated ground. It is suitable for extra heavy-duty industrial applications in indoor dry environments.

• Duplex
• Commercial/Industrial Grade
• 15A 250V
• 2-Pole 3-Wire Grounding
• 6-15R
• Isolated Ground

Product Highlights

Commercial/Industrial grade duplex receptacle with 15A 250V, 2-pole 3-wire grounding, and isolated ground.

Product Information

Standard Information

• Brand: BRYANT
• Manufacturer Part Number: BRY5662IG

Technical Specifications

• Catalog Number: BRY5662IG
• Application: Extra Heavy Duty Industrial Specification Grade
• Environmental Conditions: Indoor Dry Unless Protected By Additional Means
• EU RoHS Indicator: Yes
• Item Type: Traditional Duplex
• Material: Composite
• Material - Mounting Hardware: Screw Mounting
• OEM Brand Name: Hubbell Bryant
• Series: Extra Heavy Duty
• Style: Finder Groove Face
• Type: Duplex Receptacle
• UPC: 781786005532
• Amperage Rating: 15 A
• Connectivity: Back and Side Wired
• Current Rating: 15 A
• Phase: Single Phase
• Voltage Rating: 250 V
• Wattage: 3750
• Number Of Poles: 2-Pole
• Number Of Wires: 3-Wire
• Wire Size: #14 AWG to #12 AWG
• Nema Rating: 6-15R
