HUBBELL Bryant 71520FR Flush Receptacle 20A 3-Phase Delta 250V AC L15-20R
HUBBELL Bryant 71520FR Flush Receptacle 20A 3-Phase Delta 250V AC L15-20R
HUBBELL Bryant 71520FR Flush Receptacle 20A 3-Phase Delta 250V AC L15-20R
HUBBELL Bryant 71520FR Flush Receptacle 20A 3-Phase Delta 250V AC L15-20R

Bryant 71520FR Flush Receptacle 20A 3-Phase Delta 250V AC L15-20R

HUBBELL
Brand: HUBBELL
SKU: 71520FR
Availability: In Stock

Ships same day if ordered by 12 pm
$66.66
$66.66
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The BRYANT 71520FR is an industrial-grade flush nylon receptacle, designed for extra heavy-duty applications. Rated for 20A, 3-Phase Delta 250V AC, it features a 3-Pole 4-Wire grounding configuration and L15-20R NEMA rating. Ideal for industrial settings, this receptacle ensures secure and reliable electrical connections.

  • Combination back and side wiring terminals accept #14 through #8 AWG solid or stranded conductors
  • Heavy duty mounting straps are nickel-plated to resist corrosion, wide width design assures secure assembly
  • NEMA rating and configuration are molded into face for easy identification

Product Highlights

Industrial grade flush receptacle with combination wiring terminals and corrosion-resistant mounting straps.

Product Information

Standard Information

  • Brand: BRYANT
  • Manufacturer Part Number: 71520FR
  • Country of Origin: Mexico
Technical Specifications
Application
Extra Heavy Duty Industrial Specification Grade
Catalog Number
71520FR
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
EU RoHS Indicator
Yes
Item Type
20A Single Nylon Receptacle
Material
Composite
Material - Mounting Hardware
Screw Mounting
OEM Brand Name
Hubbell Bryant
Style
Single Receptacle
Type
Receptacle
UPC
781786695832
Amperage Rating
20 A
Connectivity
Terminal Screws
Current Amperage Description
20 Amp
Current Rating
20 A
Phase
Three Phase
Voltage Rating
3 Phase 250 VAC
Voltage Rating Description
3 Phase 250V AC
Number Of Poles
3-Pole
Number Of Wires
4-Wire
Wire Size
#14 AWG to #8 AWG
Nema Rating
L15-20R
Standards - RoHS Compliance Status
CM
Brand
Bryant
Voltage
250 VAC
Power Plug Type
No Plug
Amperage
20
Connector Type
Plug-In
Smart Home Compatibility
Not Smart Home Compatible
Total Power Outlets
1
Specification Met
NEMA
SKU
71520FR
Mfr. Part Number
71520FR
MODEL
71520FR
Country of Origin
Mexico
Manufacturer Part Number
71520FR
Manufacturer
Bryant Electric
Family Series
Bryant Electric Plugs & Receptacles
Body Type
Straight
Connection Type
Receptacle
NEMA Configuration
L15-20R
Watertight
No
Isolated Ground
No
Approvals
CSA, UL
Net Weight
0.26 lbs
Gross Weight
0.3 lbs
