Bryant 71330NC Female Connector Body 30A 3-Phase Delta 600V AC L13-30R

Product Description

The BRYANT 71330NC is an industrial female connector body designed for heavy-duty applications. Rated at 30A, 3-Phase Delta 600V AC, this 3-pole, 3-wire non-grounding connector features screw terminals and a L13-30R NEMA rating. Constructed from impact and chemical-resistant toughened nylon, it ensures durability and reliable performance in demanding environments.

• Features alignment keys for easy assembly.
• Amperage, voltage and NEMA configuration imprinted on face for easy identification.
• Internal “self-centering ” Triple Gripper® cord grip with “radius teeth ” design provides secure cord retention

Product Highlights

Durable nylon construction, secure cord retention, and easy assembly make it ideal for industrial use.

Product Information

Standard Information

• Brand: BRYANT
• Manufacturer Part Number: 71330NC
• Country of Origin: US

Technical Specifications

• Application: Heavy Duty Industrial
• Catalog Number: 71330NC
• Environmental Conditions: Indoor Dry Unless Protected By Additional Means
• EU RoHS Indicator: Yes
• Insulation: Insulated Body
• Item Type: 30A Triple Gripper Nylon Connector
• Material: Composite
• Material - Mounting Hardware: Cord Mounted
• OEM Brand Name: Hubbell Bryant
• Style: Internal Cord Clamp
• Temperature Rating: Maximum Continuous: 75 46. Nema Plug 15A 125V 3Pin 5-15R
• Type: Connector Body
• UPC: 781786694798
• Amperage Rating: 30 A
• Connectivity: Screw Terminals
• Current Rating: 30 A
• Voltage Rating: 600 VAC
• Number of Conductors: 3-Wire
• Number Of Poles: 3-Pole
• Number Of Wires: 3-Wire
• Nema Rating: L13-30R
• Standards - RoHS Compliance Status: CM
• Special Features: Standard Product
• Cord Diameter: 0.300-0.950 in
• Country of Origin: United States
