HUBBELL Bryant 71220ER Flanged Outlet 20A 3-Phase Delta 480V AC L12-20R
HUBBELL Bryant 71220ER Flanged Outlet 20A 3-Phase Delta 480V AC L12-20R

Bryant 71220ER Flanged Outlet 20A 3-Phase Delta 480V AC L12-20R

HUBBELL
Brand: HUBBELL
SKU: 71220ER
Availability: In Stock

Ships same day if ordered by 12 pm
$79.66
$79.66
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The BRYANT 71220ER is an industrial flanged receptacle, designed for heavy-duty applications. Rated at 20A, 3-Phase Delta 480V AC, this 3-pole, 3-wire non-grounding receptacle features screw terminals and impact-resistant thermoplastic construction. It is suitable for indoor dry environments and is RoHS compliant.

  • Impact resistant thermoplastic construction
  • Backwired terminations for ease of installation
  • #10-32 Multiple drive terminal screws

Product Highlights

Industrial flanged receptacle, 20A, 3-Phase Delta 480V AC, 3-Pole, 3-Wire Non-Grounding, L12-20R, Screw Terminal.

Product Information

Standard Information

  • Brand: BRYANT
  • Manufacturer Part Number: 71220ER
  • Country of Origin: US
Technical Specifications
Catalog Number
71220ER
Application
Extra Heavy Duty Industrial Specification Grade
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
EU RoHS Indicator
Yes
Item Type
20A Flanged Receptacle
Material
Composite
Material - Mounting Hardware
Screw Mounting
OEM Brand Name
Hubbell Bryant
Style
Equipment Base
Type
Flanged Receptacle
UPC
781786694101
Height
2.02 in
Length
2.88 in
Width
2.88 in
Amperage Rating
20 A
Connectivity
Terminal Screws
Current Amperage Description
20 Amp
Current Rating
20 A
Phase
Single Phase
Voltage Rating
480 V AC
Voltage Rating Description
3 Phase 480V AC
Number Of Poles
3-Pole
Number Of Wires
3-Wire
Wire Size
#14 AWG to #8 AWG
Nema Rating
L12-20R
Standards - RoHS Compliance Status
CM
Brand
Bryant Electric
Cord Diameter
0.3 to 0.655 in
Country of Origin
US
Grade
Industrial/Specification
Manufacturer Name
Hubbell
Temperature Rating
-40 to 60 deg C
Terminal Type
Screw
Description - Long
Locking Devices, Industrial, Flanged Receptacle, 20A 3-Phase Delta 480V AC, 3-Pole 3-Wire Grounding, L12-20R, Screw Terminal, White.
Description - Short
Locking Devices, Industrial, Flanged Receptacle, 20A 3-Phase Delta 480V AC, 3-Pole 3-Wire Non-Grounding, L12-20R, Screw Terminal, White
Family Color
White
FV_Current/Amperage Rating Description
20 Amp
FV_Voltage Rating Description
3 Phase 480V AC
Manufacturer
Bryant Electric, a Hubbell affiliate
Mounting
Screw Mount
Special Features
Standard Product
Class Code
A08
Sub Class Code
A08A172
Base Unit of Measure
EA
Description - Invoice
LKG FLG-RCPT, 20A 3PH 480V, L12-20R,BK
Harmonization Code
8536694020
MSDS Flag
No
Each - Pack Description
Each
Certifications
EU RoHS Indicator
