Bryant 70920NP Locking Devices Industrial Male Plug 20A 600V AC L9-20P

Product Description

The BRYANT 70920NP is an industrial male nylon plug designed for locking devices. Rated at 20A and 600V AC, this 2-pole, 3-wire grounding plug features screw terminals and a L9-20P NEMA rating. It is suitable for extra heavy-duty industrial applications and indoor dry environments.

• Hand grip features wide-rib, non-slip design
• Configuration-specific plug face surrounds blades to prevent infiltration of contaminants
• Captive, combination Slot/Phillips assembly screws

Product Highlights

Durable nylon plug with secure cord retention for industrial applications. Ideal for connecting equipment requiring a reliable locking connection.

Product Information

Standard Information

• Brand: BRYANT
• Manufacturer Part Number: 70920NP
• Country of Origin: China

Technical Specifications

• Application: Extra Heavy Duty Industrial
• Catalog Number: 70920NP
• Environmental Conditions: Indoor Dry Unless Protected By Additional Means
• EU RoHS Indicator: Yes
• Item Type: 20A Triple Gripper Nylon Plug
• Material: Nylon
• Material - Mounting Hardware: Cord Mounted
• OEM Brand Name: Hubbell Bryant
• Style: Internal Cord Clamp
• Type: Plugs
• UPC: 781786691728
• Current Rating: 20 A
• Connectivity: Screw Terminals
• Current Amperage Description: 20 Amp
• Phase: Single Phase
• Voltage Rating: 600 VAC
• Voltage Rating Description: 600 VAC
• Number Of Poles: 2-Pole
• Number Of Wires: 3-Wire
• Wire Size: #18 AWG to #8 AWG
• Nema Rating: L9-20P
• Standards - RoHS Compliance Status: CM
• Cord Type: All Listed Portables
• Manufacturer Part Number: 70920NP
• Manufacturer: Bryant Electric
• Family Series: Bryant Electric Plugs & Receptacles
• Description: Locking Devices, Industrial, Male Nylon Plug, 20A 600V AC, 2-Pole 3-Wire Grounding, L9-20P, Screw Terminal, Black and White
• Body Type: Straight
• Connection Type: Plug
• Watertight: No
• Isolated Ground: No
• Approvals: CSA, UL
• Plug Type: Locking
• Rating - Amps: 20A
• Rating - Volts: 600V
• Number of Poles: 2P
• Ground: Grounding
• NEMA: L9-20P
• Cord Diameter: 0.300 - 0.950
• Brand: Bryant
• Model: 70920NP
• MPN: 70920NP
• Country of Origin: China
