Bryant 70920NC Industrial Female Connector Body 20A 600V AC L9-20R

Product Description

The BRYANT 70920NC is an industrial female nylon connector body. Rated at 20A 600V AC, this 2-pole, 3-wire grounding connector features a L9-20R NEMA configuration and screw terminals. Its toughened nylon construction is impact and chemical resistant. Designed for heavy-duty industrial applications.

• Face and body feature alignment keys for easy assembly
• Amperage, voltage and NEMA configuration imprinted on face for easy identification
• Impact/chemical resistant, toughened nylon construction

Product Highlights

Industrial female connector body, 20A 600V AC, 2-pole 3-wire grounding, L9-20R NEMA configuration, screw terminals.

Product Information

Standard Information

• Brand: BRYANT
• Manufacturer Part Number: 70920NC

Technical Specifications

• Application: Heavy Duty Industrial
• Catalog Number: 70920NC
• Color: Black, White
• Environmental Conditions: Indoor Dry Unless Protected By Additional Means
• EU RoHS Indicator: Yes
• Insulation: Insulated Body
• Item Type: 20A Triple Gripper Nylon Connector
• Material: Composite
• Material - Mounting Hardware: Cord Mounted
• OEM Brand Name: Hubbell Bryant
• Style: Internal Cord Clamp
• Temperature Rating: Maximum Continuous: 75° C; Minimum Continuous: -40° C w/o impact, -25° with impact.
• Type: Connector Body
• UPC: 781786691698
• Display Size: Standard Sized Product
• Height: 3.9 in
• Length: 2.13 in
• Amperage Rating: 20 A
• Connectivity: Screw Terminals
• Current Amperage Description: 20 Amp
• Current Rating: 20 A
• Voltage Rating: 480 VAC
• Voltage Rating Description: 480 VAC
• Conductor Range: #14 AWG to #12 AWG
• Number of Conductors: 3-Wire Grounding
• Number Of Poles: 2-Pole
• Number Of Wires: 3-Wire
• Wire Size: #18 AWG to #8 AWG
• Nema Rating: L9-20R
• Standards - RoHS Compliance Status: CM
• Manufacturer Part Number: 70920NC
• Manufacturer: Bryant Electric
• Family Series: Bryant Electric Plugs & Receptacles
• Voltage: 600 VAC
• Body Type: Straight
• Connection Type: Connector
• NEMA Configuration: L9-20R
• Watertight: No
• Isolated Ground: No
• Approvals: CSA, UL
• Net Weight: 0 lbs
• Gross Weight: 0.4 lbs
