Bryant 70720ER Flanged Receptacle 20A 277V AC L7-20R

Product Description

The BRYANT 70720ER is an industrial flanged receptacle, designed for heavy-duty applications. Rated at 20A and 277V AC, this 2-pole, 3-wire grounding receptacle features a L7-20R NEMA configuration and screw terminals. Constructed from impact-resistant thermoplastic, it ensures durability and reliable performance in demanding environments.

• Impact resistant thermoplastic construction
• Backwired terminations for ease of installation
• #10-32 Multiple drive terminal screws

Product Highlights

Ideal for industrial settings, this flanged receptacle provides a secure and robust connection for power equipment.

Product Information

Standard Information

• Brand: BRYANT
• Manufacturer Part Number: 70720ER

Technical Specifications

• Application: Extra Heavy Duty Industrial Specification Grade
• Catalog Number: 70720ER
• Color: White
• Environmental Conditions: Indoor Dry Unless Protected By Additional Means
• EU RoHS Indicator: Yes
• Item Type: 20A Flanged Receptacle
• Material: Composite
• Material - Mounting Hardware: Screw Mounting
• OEM Brand Name: Hubbell Bryant
• Style: Equipment Base
• Type: Flanged Receptacle
• UPC: 781786690004
• Amperage Rating: 20 A
• Connectivity: Terminal Screws
• Current Amperage Description: 20 Amp
• Current Rating: 20 A
• Phase: Single Phase
• Voltage Rating: 277 VAC
• Voltage Rating Description: 277V AC
• Number Of Poles: 2-Pole
• Number Of Wires: 3-Wire
• Wire Size: #14 AWG to #8 AWG
• Nema Rating: L7-20R
• Manufacturer Part Number: 70720ER
• Manufacturer: Bryant Electric
• Family Series: Bryant Electric Plugs & Receptacles
• Voltage: 277 VAC
• Body Type: Straight
• Connection Type: Flanged Outlet
• Watertight: No
• Isolated Ground: No
• Approvals: CSA, UL
