Bryant 5384 Tech-Spec Duplex Heavy Duty Panel Mount Receptacle 125 VAC, 20 A

Product Description

The Bryant Electric 5384 Tech-Spec Straight Blade Receptacle is a duplex, heavy-duty, panel mount receptacle. Rated for 125 VAC and 20 A, it is suitable for commercial and industrial applications. Designed to withstand weather, this receptacle offers a reliable power connection in demanding environments.

• Heavy Duty Industrial
• 1.75" Mounting
• 1-3/4 in panel mounting

Product Highlights

This receptacle features a heavy-duty, copper alloy self-grounding system and is ideal for industrial applications.

Product Information

Standard Information

• Brand: BRYANT
• Manufacturer Part Number: 5384
• Country of Origin: PR

Technical Specifications

• Application: Heavy Duty Industrial
• ARRA Compliant: Y
• Buy American Compliant: Y
• Catalog Number: 5384
• Country of Origin: PR
• Environmental Conditions: Weather Resistant
• EU RoHS Indicator: Y
• Grade: Commercial/Industrial
• Material: Composite
• NEMA Rating: 5-20R
• Number Of Poles: 2
• Phase: 1
• Standards: ARRA CompliantBuy American Act CompliantRoHS CompliantNEMA WD1/WD5UL 498
• Terminal Type: Screw
• Type: 1-Phase Duplex Grounding Heavy Duty Standard Weather Resistant
• UNSPSC: 39121406
• Wattage: 2,500 W
• Wire Size: #14 AWG to #12 AWG
• Brand: Bryant
• Manufacturer: Hubbell
• Amperage Rating: 20 A
• Number of Wires: 3
• Voltage Rating: 125 VAC
• Current Rating: 20 A
• Connection Type: Receptacle
• Wiring Method: Side
• Ground: Grounding
• Application Grade: Industrial
