Bryant 4903GLI Illuminated Industrial Grade Toggle Switch, 20A 120/277V AC

Product Description

The BRYANT 4903GLI is an illuminated industrial-grade toggle switch designed for general-purpose AC applications. This three-way switch supports 20A at 120/277V AC and features back and side wiring. It is suitable for industrial environments. The switch features light on with load off.

• Rated for 20A at 120/277V AC
• Features back and side wiring
• Illuminated with light on when load is off

Product Highlights

Industrial grade, three-way toggle switch with illumination and back/side wiring.

Product Information

Standard Information

• Brand: BRYANT
• Manufacturer Part Number: 4903GLI
• Country of Origin: China

Technical Specifications

• Application: Back and Side Wired
• Catalog Number: 4903GLI
• Series: Extra Heavy Duty
• Style: Three Way
• Type: Toggle
• Amperage Rating: 20 A
• Current / Amperage Rating: 20 A
• Voltage Rating: 120/277 VAC
• Voltage Rating Description: 120/277 VAC
• Brand: BRYANT
• Model: 4903GLI
• MPN: 4903GLI
• UPC: 781786623965
• Amps: 20 Amps
• Features: Illuminated
• Overall Width: 1.9 in
• Overall Height: 1.7 in
• Item: Illuminated Wall Switch
• Switch Type: 3-Way
• Switch Style: Toggle
• Amps AC: 20 A
• Voltage AC: 120 to 277
• Locking: No
• Switch Function: Maintained
• Wiring Method: Back, Side
• Application Environment: Industrial
• Antimicrobial: No
• Description/Special Features: Light On with Load Off
• Rated HP: 1 to 2
• Standards: NEMA WD-1, UL20
• Current Rating: 20 A
• Horsepower Rating: 2 hp
• Illuminated: Yes
• Locking Style: Not Applicable
• Market: Industrial
• Number of Switches: 1
• Wire Connection Type: Screw Terminals
