Browning BK40H CLEAR PK V-Belt Pulleys - 4L or A, 5L or B Belt Section, 1 Groove, 3.4000 in (A) 3.9000 in (B) Pitch Dia., 3.9500 in O.D., Split Taper Bushed, H Series Bushing, Cast Iron Material

Product Description

The Browning BK40H CLEAR PK is a 1 groove cast iron sheave designed for use with 4L or A and 5L or B belts. With an outside diameter of three point nine five inches, this sheave is built for reliability in fractional horsepower applications.

• Compatible with A, 4L, B, and 5L belts
• Statically balanced for smooth operation
• Manufactured from close grain cast iron for precise machining

Product Highlights

This sheave provides a combination groove allowing versatility in belt types, meeting various horsepower requirements and pitch diameters.

Product Information

Standard Information

• Product Type: Classical Gripbelt Sheave
• Brand: Browning

Technical Specifications

• Material: Cast Iron
• Weight: 1.6 lbs
• Bore (Max): 1-1/2 inches
• Bore (Min): 0.38 inches
• Outside Diameter: 3.95 inches
• Grooves: 1
• Shipping Dimensions: 7.85 x 5.55 x 1.15 inches
• Belt Type: 4L, 4L or A, A, 5L or B, 5L, B
