Browning 1297704 Double Strand 50 Chain Connecting Link

Product Description

The BROWNING 1297704 is a steel connecting link designed for double strand roller chain with a 5/8 inch pitch and ANSI number 50-2. It provides a removable, field-serviceable joint for joining or repairing double strand chain runs. The link attaches via a pin-style closure and is built to ANSI standards for dimensional consistency. With a roller diameter of 0.400 inches and a roller width of 0.375 inches, the link matches the geometry of standard 50-2 chain. Typical installers include industrial maintenance technicians, conveyor system mechanics, and equipment service professionals who work with chain-driven machinery.

This connecting link is suited for use in industrial drive and conveyor applications where double strand ANSI 50-2 roller chain is specified. Common install scenarios include agricultural equipment, material handling conveyors, light industrial drives, and general power transmission systems that require periodic chain removal or replacement. The pin-style attachment allows the link to be installed and removed with standard hand tools without cutting the chain.

Key Features

• Designed for double strand roller chain with 5/8 inch pitch
• ANSI 50-2 rated for dimensional compliance with standard chain
• Steel construction for durability in drive and conveyor applications
• Pin-style attachment for tool-accessible field installation and removal
• Roller diameter of 0.400 inches and roller width of 0.375 inches match standard 50-2 chain geometry

Compatibility

Designed as an OEM-style replacement connecting link for ANSI 50-2 double strand roller chain applications.

Installation Notes

Installation is typically performed by industrial maintenance technicians or equipment mechanics. De-energize and lock out the drive system before installing or removing any chain link. Use appropriate chain tools to align the link and seat the retaining clip or cotter pin fully before returning the drive to service. Follow applicable ANSI and equipment manufacturer guidelines for chain tension and lubrication after installation.
