Browning 1095710 5L Series Wrapped V-belt 85 in

Product Description

The BROWNING 1095710 is a 5L series wrapped V-belt designed for power transmission in HVAC, agricultural, and industrial equipment applications. With an 85-inch length and a 21/32-inch top width, this belt suits a wide range of drive systems using standard 5L-profile sheaves. The wrapped construction uses a fabric cover over the cord and rubber body, which smooths engagement, reduces operating noise, and resists the heat and oil exposure common in mechanical drive environments. Static-conducting construction helps dissipate static charge buildup during operation. Licensed HVAC technicians, millwrights, and equipment service techs are the typical installers.

The 1095710 is used in residential and light commercial HVAC blower drives, fan assemblies, pump drives, and general industrial belt-drive systems that specify a 5L-profile belt. It is formulated for flexibility on smaller-diameter sheaves, making it well suited for compact drive configurations where bending radius is a limiting factor. The industry standard cross-reference part number for this belt is 5L850, which can be used when sourcing across multiple supply channels.

Key Features

• Wrapped construction for smooth, quiet power transmission and reduced vibration
• Oil and heat resistant compound extends service life in demanding drive environments
• Static-conducting design dissipates charge buildup during continuous operation
• Formulated for flexibility on smaller-diameter sheaves without accelerated wear
• Cross-references to industry part number 5L850 for multi-source sourcing compatibility

Compatibility

Designed as an OEM-style replacement for drive systems specifying a 5L-profile wrapped V-belt with an 85-inch outside length. Industry cross-reference: 5L850.

Installation Notes

Belt installation should be performed by a qualified technician with power fully disconnected and locked out at the disconnect or breaker before accessing the drive. Never pry a belt over a sheave under tension; always release drive tension via the adjustment mechanism before removal and reinstallation. After installing the new belt, set tension per the equipment manufacturer specification and verify alignment of sheaves before restoring power. Inspect sheave grooves for wear or damage that could accelerate belt wear prematurely.

Technical Specifications

• Belt Series: 5L
• Construction: Wrapped
• Belt Length: 85 inches
• Top Width: 21/32 inches
• Industry Part Number: 5L850
• Shipping Weight: 0.60 pounds
• Shipping Dimensions: 13 inches x 4 inches x 2 inches

Standard Information

• Brand: BROWNING
• Manufacturer Part Number: 1095710
