Browning 1094127 Fhp Belt 3L 3/8 in X 54 in Neoprene

Product Description

The BROWNING 1094127 is a non-cogged fractional horsepower (FHP) V-belt in the 3L section, built for light-duty power transmission applications in HVAC equipment, small motors, and general mechanical drives. The belt measures 3/8 inch wide at the top, 54 inches in outside length, and 7/32 inch thick. Constructed from neoprene with cotton reinforcement, it delivers reliable flexibility and heat resistance in demanding service environments. The non-cogged design provides a smooth, consistent contact surface suited for standard FHP sheaves and pulleys. Licensed HVAC technicians and mechanical service professionals handle this type of belt replacement as routine preventive maintenance.

This belt is a direct-fit replacement for 3L-section FHP applications found in residential and light commercial HVAC systems, blower assemblies, small air handlers, and auxiliary mechanical equipment. The 3L section designation identifies it within the standard fractional horsepower belt family, making cross-referencing straightforward against OEM belt specifications. Its 54-inch outside length and 3/8-inch top width must be matched precisely to the existing sheave groove profile before installation.

Key Features

• 3L section designation for standard FHP sheave compatibility
• 3/8 inch top width and 54 inch outside length for precise fitment
• Neoprene construction with cotton reinforcement for durability and flex life
• Non-cogged design provides smooth contact surface on standard pulleys
• Rated to 140 degrees F for use in warm mechanical enclosures
• Single-rib profile matches standard single-groove FHP sheaves

Compatibility

Designed as an OEM-style replacement for fractional horsepower drive systems using 3L-section V-belts with a 54-inch outside length and 3/8-inch top width groove profile.

Installation Notes

Belt replacement on FHP drives is typically performed by licensed HVAC technicians or qualified mechanical service personnel. Always disconnect and lock out power to the motor before removing the belt guard or accessing the drive. Adjust center distance on the drive to allow belt installation without forcing it over the sheave flanges, then re-tension according to the equipment manufacturer's deflection specification. Inspect sheave grooves for wear or glazing before installing a new belt, as damaged grooves will shorten belt service life.

Technical Specifications

• Section: 3L
• Top Width: 3/8 inches
• Outside Length: 54 inches
• Thickness: 7/32 inches
• Number of Ribs: 1
• Max Temperature Rating: 140 degrees F
• Material: Neoprene, Cotton Reinforced
• Color: Black
• Belt Type: Non-Cogged FHP V-Belt

Standard Information

• Brand: BROWNING
• Manufacturer Part Number: 1094127
