Browning 1094101 Non-cogged Fhp Belt 3L 3/8 in 52 in Neoprene

Product Description

The BROWNING 1094101 is a non-cogged fractional horsepower (FHP) V-belt in the 3L section, designed for light-duty power transmission on small-motor applications. It measures 3/8 inch wide at the top, 52 inches in outside length, and 7/32 inch thick. Constructed from neoprene with cotton reinforcement, it delivers reliable flex and heat resistance up to 140 degrees F. HVAC technicians and equipment service pros reach for this belt when replacing worn drive belts on fractional-horsepower motors in fans, blowers, and small-equipment drives.

This belt is suited for residential and light commercial applications where a 3L-section FHP belt is specified. Typical install scenarios include replacement of drive belts on small blower assemblies, evaporative coolers, and other equipment using compact sheave-and-belt drive systems. It is installed by HVAC technicians or general equipment mechanics as part of routine preventive maintenance or in response to belt wear, slipping, or breakage.

Key Features

• 3L section profile with 3/8 inch top width fits standard 3L-compatible sheaves
• 52 inch outside length suits a range of small-motor drive configurations
• Non-cogged construction provides a smooth, consistent drive surface
• Neoprene body with cotton reinforcement resists heat and flex fatigue
• Rated to 140 degrees F for use in warm equipment enclosures
• Black finish; single-rib design for single-groove sheave applications

Compatibility

Designed as an OEM-style replacement for equipment specifying a 3L-section non-cogged fractional horsepower belt with a 52 inch outside length and 3/8 inch top width.

Installation Notes

Installation is typically performed by an HVAC technician or qualified equipment mechanic. Always power down and lock out the unit before removing or installing a drive belt. Adjust sheave spacing to allow belt seating without prying, then tension according to the equipment manufacturer's deflection specification. Inspect sheave grooves for wear or misalignment before installing a new belt to avoid premature failure.

Technical Specifications

• Type: Non-Cogged
• Section Size: 3L
• Top Width: 3/8 inches
• Outside Length: 52 inches
• Thickness: 7/32 inches
• Number of Ribs: 1
• Temperature Rating: 140 degrees F
• Material: Neoprene
• Reinforced Material: Cotton
• Color: Black

Standard Information

• Brand: BROWNING
• Manufacturer Part Number: 1094101
