Browning 1001791 Qd Bushed V Belt Sheave 2 Groove

Product Description

The BROWNING 1001791 is a two-groove, QD bushed V belt sheave designed for industrial belt drive systems. Built from cast iron, it accepts standard A and B section belts as well as 5V belts, with a belt pitch A diameter of 5.0 inches and a belt pitch B diameter of 5.4 inches. The outside diameter measures 5.75 inches. The QD (Quick Detachable) bushing interface uses a P1 bushing style, allowing fast installation and removal without specialized tooling. HVAC equipment technicians and industrial maintenance pros install this sheave on blower and fan drive assemblies where precise belt alignment and secure shaft engagement are required.

This sheave fits blower fan drive applications common in commercial and light industrial HVAC systems, as well as general-purpose belt drive machinery. It accommodates bore diameters from 0.5 inches up to 1.5 inches, making it compatible with a range of shaft sizes typically found in air handler blowers, exhaust fans, and similar rotating equipment. The two-groove configuration suits dual-belt drive setups where load sharing or redundancy is needed.

Key Features

• Two-groove design supports dual A, B, or 5V section V belts
• QD bushing interface with P1 bushing style for fast, secure shaft mounting
• 5.75 inch outside diameter with 5.0 inch belt pitch A diameter and 5.4 inch belt pitch B diameter
• Bore range of 0.5 to 1.5 inches accommodates multiple shaft sizes
• Cast iron construction for durability in belt drive service

Compatibility

Designed as an OEM-style replacement or upgrade sheave for two-groove V belt drive systems using A, B, or 5V section belts with a P1 QD bushing. No specific model compatibility data was provided in the product input.

Installation Notes

Installation and removal should be performed by a qualified mechanic or HVAC technician following established lockout/tagout procedures before working on any rotating equipment. The QD bushing must be sourced separately and seated fully before torquing fasteners. Verify belt section and sheave groove profile match before final assembly. Follow the drive manufacturer guidelines and applicable ANSI or OSHA standards for belt drive service.
