Bromic Heating BH3130053 Affinity Smart-Heat On/Off Controller 5 Channel

Product Description

The Bromic Heating BH3130053 Affinity Smart-Heat On/Off Controller allows Platinum or Tungsten Collection gas or electric Bromic heaters to be turned on or off at full power. This 5 channel model can control up to 6000W of power or 10 gas heaters per channel. Control and customize settings via Wi-Fi or Bluetooth using the Bromic Heating App.

• Gas or Electric Compatible
• Wi-Fi & Bluetooth Enabled
• Each channel controls up to 6,000W of power or 10 gas heaters

Product Highlights

The Bromic Heating Affinity Smart-Heat On/Off Controller offers effortless outdoor heating control for Platinum and Tungsten Collection heaters.

Product Information

Standard Information

• Brand: Bromic Heating
• Manufacturer Part Number: BH3130053

Technical Specifications

• MODEL: AFFINITY ON/OFF
• PART NUMBER: BH3130053
• NUMBER OF CHANNELS: 5 CH
• VOLTAGE-MAX CAPACITY PER CHANNEL: 3N-220/380V – 6kW 3N-230/400V – 6kW 3N-240/415V – 6kW 3N-277/480V – 6kW 3- 120/208V – 6kW
• OPERATING TEMPERATURE RANGE: -4°F to +86°F
• NON-OPERATING TEMPERATURE RANGE: -22°F to +158°F
• PROTECTION RATING: IP54
• WIFI CONNECTIVITY: 2.4GHZ
• APPROVAL CERTIFICATION: UL 60730-1, CAN/CSA E60730-1
• HEATER COMPATIBILITY: Platinum Electric & Tungsten Electric
• Phase: 3 Phase
• Voltage: 110 - 277 Volts
• Wattage: 6,000 Watts
• Features: Bluetooth, WiFi Enabled
• Product Line: Bromic Heating Affinity
• Type: Add-On Accessories
• Controls: Remote Controls
• Number of Channels: 5
• Max Power Output per Channel: 6kw
• Total Power Output: 30kw
• Capabilities: Bluetooth & WIFI
