Broan-Nutone ZN110 Ultra Multi-Speed Energy Star Fan 110 CFM

Product Description

The Broan-NuTone ZN110 Ultra Multi-Speed Energy Star Fan operates from 30 CFM to 110 CFM with less than 0.3 Sones. ULTRASmart DC Motor & Control Technology provides energy efficiency almost 10 times greater than ENERGY STAR requirements and maintains rated power (CFM) in nearly every installation. It is suitable for bathrooms up to 105 square feet.

• Features ULTRAQuick Installation Technology for up to 60% faster installation in retrofits.
• Equipped with a unique telescoping mounting frame that expands from 14" to 24" for easy placement.
• Operates at less than 0.3 Sones for ultra-silent performance.

Product Highlights

This multi-speed fan offers premium ventilation, energy efficiency, and quiet operation. Ideal for reducing airborne pollutants and managing moisture in bathrooms.

Product Information

Standard Information

• Brand: BROAN-NUTONE
• Manufacturer Part Number: ZN110
• Country of Origin: China

Technical Specifications

• Type: Multi-Speed DC Motor Fan
• Brand: Broan-NuTone
• Wattage: 7.7 Watt
• Amperage: 0.2 Amp
• Standard: Energy Star Certified,HVI 2100 Certified,UL Listed For Use Over Bathtubs And Showers When Connected To A GFCI Protected Branch Circuit (Ceiling Mount Only)
• Duct Size: 6 in
• Sub Brand: Ultra
• Light Type: No Light
• Nightlight: No
• Rated Sones: <0.3
• Applications: For Bathrooms Up To 105 SQ-FT
• Grille Width: 14 in
• Grille Length: 13 in
• Housing Width: 11-3/8 in
• Housing Height: 7-5/8 in
• Housing Length: 10-1/2 in
• Grille Material: Polymeric
• CFM: 110
• MPN: ZN110
• Product Type: ELECTRIC_FAN
• Manufacturer: Broan-NuTone
• Model / MPN: ZN110
• Product Group: Home Improvement
• Air Flow Capacity: 110 Cubic Feet Per Minute
• Voltage: 110 Volts
• Number of Blades: 3
• Model Name: 686315
• Model Number: 686315
• Blade Length: 100 Millimeters
• Country of Origin: China
