Product Description
The Broan-NuTone XB50L ULTRA GREEN Series Fan/LED Lights deliver premium ventilation to help reduce airborne pollutants. It features quiet operation and energy efficiency. The fan is designed for spot ventilation in humid bathrooms, and continuous ventilation to meet building codes and Green Building standards. The single speed ventilation fan has a power usage of 120-volt and amperage capacity 0.7 amps.
- Powerful ventilation reduces humidity to quickly eliminate fogged mirrors and manage moisture.
- ULTRASilent Sound Technology results in operation at less than 0.3 sones.
- ULTRAQuick Installation Technology uses an exclusive telescoping mounting frame with pre-installed screws.
Product Highlights
This ventilation fan provides premium ventilation, quiet operation, and energy efficiency. Ideal for bathrooms, it meets building codes and Green Building standards.
Product Information
Standard Information
-
Brand: Broan-NuTone
-
Manufacturer Part Number: XB50L
-
Country of Origin: USA
Technical Specifications
-
Type: Single-Speed DC Motor Fan
-
Brand: Broan-NuTone
-
Voltage: 120 Volt
-
Wattage: 2-18 Watt
-
Amperage: 0.8 Amp
-
Standard: Energy Star Certified, HVI 2100 Certified, UL Listed For Use Over Bathtubs And Showers When Connected To A GFCI Protected Branch Circuit (Ceiling Mount Only) And For Use In Insulated Ceilings (Type IC)
-
Duct Size: 4 in
-
Sub Brand: Ultra
-
Light Type: Fluorescent
-
Product UPC: 02671520125
-
12-Digit UPC: 026715201259
-
Airflow Rate: 50 CFM
-
Applications: For Bathrooms
-
Grille Width: 13-3/4 in
-
Bulb Included: Yes
-
Grille Length: 13 in
-
Housing Width: 11-3/8 in
-
Housing Height: 7-5/8 in
-
Grille Material: Polymeric
-
Airflow Capacity: 50 CFM
-
Motor Technology: DC motor technology
-
Sound Level (Sones): 0.3
-
ENERGY STAR�� certified: Yes
-
UL Listed: Yes
-
Grille Finish: White
-
Humidity Sensing: No
-
Motion Sensing: No
-
Motor Engineered For Continuous Operation: Yes
-
Night Light: No
-
Radiation Damper Available: Yes
-
Room Side Installation: Yes
-
UL Listed for use over bathtubs or showers when connected to a GFCI circuit: Yes
-
Heater Wattage: 0
-
Recommended Room Size (Sq Ft): 45
-
Rated Amps: 0.3
-
Can Be Used To Comply With Title 24: Yes
-
Minimum Construction Space Required: 2" x 8"
-
High Efficiency Luminaire: No
-
Minimum Recommended Flow: 0
-
Catalog Number: XB50L
-
Country of Origin: USA
-
Mounting Type: Ceiling
-
Standards: Energy Star Certified, HVI 2100 Certified, UL Listed
-
Fixture Wattage: 5.3/4.9 W
-
Housing Material: Polymer
-
Lamp Type: Fluorescent
-
Voltage Rating: 120 VAC
-
Frequency Rating: 60 Hz
-
Power Rating: 4.9 W at 0.1 in Static Pressure
-
Material: Polymeric
-
Length: 10-1/2 in
-
Width: 11-3/8 in
-
Height: 7-5/8 in
-
Grille Size: 13 in L x 13-3/4 in W
-
CFM Rating: 50 cfm at 0.1 in SP
