Brizo 69475-SL Grab Bar European Round ADA Concealed Mount Metal 18 Inch

Product Description

The BRIZO 69475-SL Grab Bar is an 18-inch linear round safety accessory designed for support. It features a 1 1/4 inch diameter bar and 3 inch diameter flanges. This wall-mounted grab bar extends 2 3/4 inches from the wall, providing 1 1/2 inches of wall clearance. It incorporates concealed mounting and includes all necessary hardware and a retrievable wall anchor. Engineered to support up to 500 lbs of force, it exceeds ADA requirements.

• 1 1/4 inch diameter bar with 3 inch diameter flanges.
• Concealed mounting with included hardware and retrievable wall anchor.
• Supports up to 500 lbs of force, exceeding ADA requirements.

Product Highlights

This 18-inch linear round grab bar provides robust support with concealed mounting and a 500 lbs load capacity.

Product Information

Standard Information

• Brand: BRIZO
• Manufacturer Part Number: 69475-SL
• Country of Origin: China

Technical Specifications

• Brand: Brizo
• Finish Color: Stainless Steel Tones
• Finish Name: Luxe Steel
• Commercial or Residential Use: Primarily Residential
• Bar Diameter: 1 1/4 inches
• Flange Diameter: 3 inches
• Extension from Wall: 2 3/4 inches
• Wall Clearance: 1 1/2 inches
• Mounting: Concealed
• Load Capacity: 500 lbs.
• Product Type: Bathroom Safety Equipment
• Installation Hardware Included: Yes
• Concealed Screws: Yes
• Installation Type: Wall Mounted
• Material: Metal
• Shape: Straight
• Theme: Modern
• ADA: Yes
• Approved for Commercial Use: Yes
• Model Name: 69475 SL
