Bridgeport Fittings 665-DC2 1-1/2 in. 2-Screw Non-Metallic Cable Connection with Strap

Product Description

The BRIDGEPORT FITTINGS 665-DC2 is a 1-1/2 inch 2-Screw Non-Metallic Cable Connection with Strap. This die-cast zinc connector is designed for securing non-metallic or round service entrance cables to a box or enclosure. It accommodates cable openings from 1.187 to 1.49 inches and features a ball burnished, mirror smooth finish. The connector is equipped with a 2-way Phillips/slotted head screw for installation.

• Designed for non-metallic or round cable applications.
• Constructed from durable die-cast zinc with a ball burnished, mirror smooth finish.
• Features a 2-way Phillips/slotted head screw for secure installation.

Product Highlights

Securely connects non-metallic or round service entrance cables to electrical enclosures.

Product Information

Standard Information

• Brand: BRIDGEPORT FITTINGS
• Manufacturer Part Number: 665-DC2

Technical Specifications

• Approval: UL 514B, NEMA FB-1, CSA LR39354 Certified, Federal Specification A-A-50552
• Cable Opening Range: 1.187 to 1.49 Inch
• Cable Type: Non-Metallic Cable/Service Entrance Cable
• Installation: 2 Screw Strap
• Knockout Size: 1-1/2 Inch
• Manufacturer: Bridgeport Fittings
• Material: Die-Cast Zinc
• UPC: 781747156655
• Throat Shape: Round Shape
• Finish: Ball Burnished/Mirror Smooth
• Connector Type: Two-Screw Strap-Type NM Cable Connector
• Series: 665
• Screw Type: Phillips/Slotted Head Screw
• Angle: 180 deg
• Overall Diameter: 3-1/2 in
• Overall Length: 2-7/8 in L
