Product Description
The Bridgeport 501-DC2 is a die cast connector designed for steel or aluminum armored cable connections. This set screw connector provides reliable and durable performance for connecting cables to boxes or enclosures. It accommodates a cable diameter ranging from zero point four three to zero point six one inches and is suitable for use with steel armored and interlocked MC cables. The threaded mount ensures a secure fit.
- Non-insulated connector for secure cable connections
- Compatible with multiple cable types including AC, MC, and MCI-A
- Made from die cast zinc with a smooth finish
Product Highlights
This connector is commonly used in electrical installations to connect armored cables to junction boxes or other electrical enclosures. It features a simple installation process and is ideal for both new installations and repairs.
Product Information
Standard Information
-
Brand: Bridgeport
-
Manufacturer Part No: 501-DC2
Technical Specifications
-
Type: Non-Insulated
-
Application: Steel armored cable connection
-
Diameter Range: 0.43 to 0.61 inches
-
Conductor Range: 14/2 to 10/3
-
Finish: Ball Burnished
-
Material: Zinc Die Cast
-
NEMA Rating: FB-1
-
Country of Origin: United States
-
Special Features: Furnished with 2-way Phillips/slotted head screw
