Bridgeport 383 Bushing, Insulated, Grounding, Malleable Iron, Size 1 Inch

Product Description

The BRIDGEPORT 383 is an insulated grounding bushing made of malleable iron with a size of 1 inch. It is used with a locknut to terminate service conduit to a cabinet. A lug is provided for bonding a jumper to a neutral busbar. The bushing is zinc electroplated and suitable for use on IMC/Rigid Conduit.

• Made of malleable iron for durability
• Features a grounding lug with a wire capacity of #14 - #4 AWG
• Insulated throat to protect wires

Product Highlights

This grounding bushing is ideal for terminating service conduit to cabinets, ensuring a secure and grounded connection.

Product Information

Standard Information

• Brand: BRIDGEPORT
• Manufacturer Part Number: 383
• Country of Origin: China

Technical Specifications

• Catalog Number: 383
• Manufacturer: Bridgeport Fittings, LLC
• Brand: Bridgeport
• Country of Origin: China
• Made in USA: No
• Application: Used with locknut to terminate service conduit to cabinet. Lug provided for bonding jumper to neutral busbar.
• Finish: Zinc electro-plate
• Material: Malleable Iron
• Special Features: Grounding Lug Wire Capacity #14 - #4
• Standard: cULus
• Item Type: Bushing
• Size: 1 IN
• Temperature Rating: 150 Degrees C
• Trade Size: 1 Inch
• Type: Threaded
• Wire Size: 14 AWG Solid to 4 AWG Stranded
• Lug Type: Tin Electroplated Aluminum Alloy
• Throat Type: Insulated
• Diameter: 1-1/2 Inch
• Height: 9/16 Inch
• Approval: UL 514B, UL (Canada and US)
• Used On: IMC/Rigid Conduit
• ROHS Compatible: True
• Applicable Standard: Federal Specification A-A-50553, NEMA FB-1
• Insulator Material: Nylon
• ECCN: EAR99
• UPC: 78174700383
• UNSPSC: 39121312
• Lug Capacity: 14 to 4 AWG
• GTIN: 00781747013835
• Ul Standard: UL-514B
• 12-Digit UPC: 781747003836
• GTiN: 00781747003836
• Product UPC: 78174700383
