Breeze WFPU17Z243C outdoor inverter heat pump condenser 2 ton 230V

Product Description

The BREEZE WFPU17Z243C is an efficient outdoor inverter heat pump condenser designed to upgrade traditional HVAC systems. It features universal compatibility, pairing with virtually all existing HVAC systems, regardless of brand. The high-performance compressor accommodates linesets up to 246 ft. and height differentials of up to 98 ft. Operates in temperatures down to -13� F in heat pump mode and provides cooling as low as 5� F.

• Universal Compatibility: Pairs with virtually all existing HVAC systems.
• Accommodates Long Lineset Runs: Up to 246 ft. linesets and 98 ft. height differentials.
• Space Saving Slim Design: Ultra-compact design features a smaller footprint.

Product Highlights

This BREEZE heat pump condenser offers energy-saving efficiencies, precise temperature control, and low sound levels for a comfortable environment.

Product Information

Standard Information

• Brand: BREEZE
• Manufacturer Part Number: WFPU17Z243C

Technical Specifications

• Ton: 2
• Brand: Breeze
• Hertz: 60 Hz
• Phase: 1
• Voltage: 230 V
• Amperage: 11.2 A
• Decibels: 54
• Horsepower: 5/16 HP
• BTU Cooling: 22000
• BTU Heating: 26000
• Refrigerant: R-410A
• Number of Speeds: Variable
• Manufacturers Part Number: WFPU17Z243C
• Certifications: AHRI Certified, UL Listed, CSA, Energy Star, ETL Listed
• Cooling Capacity: 22,000 Btu/h
• Heat Capacity: 26,000 Btu/h
• Electrical Voltage: 208/230V
• Frequency: 60Hz
• Rated Load Amperes (RLA): 11.2
• Sound Level: 54 dB(A)
• Refrigerant Type: R410A
• Application: Ducted Heat Pump Outdoor
• Heating Capacity (Btu/h): 23000
• SEER2 / EER2: 16.50 / 10.10
• HSPF2 / COP: 9.0 / 2.05
• System Cooling Temp Range: 61�F to 86�F (16�C to 30�C)
• System Heating Temp Range: 61�F to 86�F (16�C to 30�C)
• Sound Pressure Level (Cooling / Heating) dB(A): 54
• Line Set Size (Liquid - Gas): 3/8 - 5/8
• Voltage Data (Volts-Phase-Hz): 208/230/1/60
• Air CFM Volume: 1825 CFM
• Cooling - �F (�C): 61�F to 86�F (16�C to 30�C)
• COP2: 2.05 (@ 5 �F)
• EER2: 10.10
• Gas Connection Size: 5/8"
• Heating - �F (�C): 61�F to 86�F (16�C to 30�C)
• Liquid Line: 3/8"
• Max Circuit Breaker: 25
• MCA: 15
• Moisture Removal pints/h: 4.6
• HSPF2: 9.00
• SEER2: 16.5
