Breeze WFH60Z223C Communicating Indoor Air Handler with A-Coil, 5 Ton, 1 PH, 230V

Product Description

The Breeze WFH60Z223C is an indoor air handler designed to upgrade traditional ducted HVAC systems to an efficient inverter heat pump system. Compatible with existing HVAC systems, it accommodates long lineset runs up to 246 ft. Its slim design saves space, and the precision inverter delivers efficiencies up to 18.0 SEER2 and 9.5 HSPF2.

• Universal Compatibility with existing HVAC systems
• Accommodates Long Lineset Runs up to 246 ft
• Space Saving Slim Design

Product Highlights

This air handler provides precise temperature control, operates in low temperatures down to -13� F, and features quiet air movement with sound levels as low as 38 dB.

Product Information

Standard Information

• Brand: BREEZE
• Manufacturer Part Number: WFH60Z223C

Technical Specifications

• Ton: 5
• Brand: Breeze
• Hertz: 60 Hz
• Phase: 1
• Voltage: 230 V
• Amperage: 31 A
• Decibels: 65 dB(A)
• Horsepower: 3/4 HP
• BTU Cooling: 56000
• BTU Heating: 57500
• Refrigerant: R-410A
• Number of Speeds: Variable
• Manufacturers Part Number: WFH60Z223C
• Certifications: AHRI Certified, UL Listed, CSA, Energy Star, ETL Listed
• Airflow Rate Rated: 1706 CFM
• Liquid Connection Size: 3/8��_
• Gas Connection Size: 7/8��_
• Max Circuit Breaker: 15
• MCA: 6.8
• Rated Load Amperage (RLA): 31.0
• Cooling ��� �F (�C): 61�F to 86�F (16�C to 30�C)
• Heating ��� �F (�C): 61�F to 86�F (16�C to 30�C)
• Moisture Removal pints/h: 4.6
• SEER2: 17
• EER2: 8.25
• HSPF2: 8.50
• COP2 @ 5 �F: 2.90
• ENERGY STAR�: No
