Breakers Unlimited HOM240 Homeline Standard Miniature Circuit Breaker

Product Description

The Breakers Unlimited HOM240 is a Square D Homeline standard miniature circuit breaker. This two-pole breaker is rated for one hundred twenty to two hundred forty VAC with a forty A capacity. It has a ten kA interrupt rating and provides protection against overloads and short circuits. The K-Curve/Thermal Magnetic trip type ensures reliability and safety. This breaker is designed for plug-on mounting and is compatible with eight to two AWG aluminum or copper wire.

• Two-pole design with forty A rating
• Interrupt rating of ten kA
• Suitable for use with eight to two AWG wire

Product Highlights

Product Information

Standard Information

• Brand: Square D
• MPN: HOM240

Technical Specifications

• Amperage Rating: forty A
• Connection Type: Screw
• Dimensions: two point ninety-eight inches L x two inches W x three point thirteen inches H
• Frequency Rating: fifty/sixty Hz
• Mounting Type: Plug-On
• Number of Phases: one
• Number of Poles: two
• Voltage Rating: one hundred twenty/two hundred forty VAC
• Wire Size: eight to two AWG
