BRAVO ROMA BRV-P24DT230VI Ducted Slim Mini Split Heat Pump 24K BTU

Product Description

The BRAVO ROMA BRV-P24DT230VI is a 24,000 BTU/h slim duct mini split heat pump designed for concealed installation in residential and light commercial applications. This single-zone system delivers year-round comfort through efficient cooling and heating performance, integrating seamlessly into ceiling or soffit spaces for discreet climate control without visible wall-mounted units.

Ideal for new construction, renovations, and retrofit applications where aesthetic integration matters, the slim duct profile fits tight plenum spaces while distributing conditioned air through existing or new ductwork. The system supports smart device control and includes comprehensive installation hardware for professional HVAC contractors.

Key Features

• 24,000 BTU/h cooling and heating capacity with inverter-driven compressor technology
• Slim duct design for concealed ceiling, soffit, or mechanical room installation
• R32 refrigerant with lower global warming potential than R410A
• Smart App connectivity for remote temperature and scheduling control
• AHRI certified performance for verified efficiency ratings
• 208-230V single-phase power supply compatible with standard residential electrical service

Compatibility

This indoor unit pairs exclusively with BRAVO ROMA outdoor models designated for 24K BTU capacity at 208-230V, 1-phase, 60Hz operation. Verify outdoor unit model compatibility with BRAVO distributor before system commissioning. Not compatible with multi-zone outdoor units or other BRAVO series configurations.

Installation Notes

Professional installation by licensed HVAC technician required per manufacturer warranty terms. Unit requires minimum service clearances per installation manual. Refrigerant lines, condensate drain, and low-voltage wiring field-provided. Support framing and duct connections fabricated on-site to application requirements.

Technical Specifications

• Cooling/Heating Capacity: 24,000 BTU/h
• Power Supply: 208-230V, 1Ph, 60Hz
• Refrigerant Type: R32
• System Type: Single-zone ducted mini split heat pump
• SEER2: Up to 17 (system-dependent on matched outdoor unit)
• Control: Wireless remote and Smart App included

Standard Information

• Brand: BRAVO ROMA
• MPN: BRV-P24DT230VI
• Country of Origin: Not specified in available documentation
