BRAVO ROMA BRV-P18DT230VI Slim Duct Mini Split Heat Pump 18000 BTU

Product Description

The BRAVO ROMA BRV-P18DT230VI is a slim duct indoor unit designed for single-zone and multi-zone mini split applications. This 18,000 BTU capacity unit delivers efficient cooling and heating performance using environmentally conscious R32 refrigerant with lower global warming potential. The slim duct configuration allows for concealed installation above ceilings or in soffits, providing conditioned air through ductwork for a clean, unobtrusive aesthetic ideal for residential and light commercial environments.

Engineered for 208-230V single-phase power systems, this unit integrates with BRAVO ROMA outdoor condensers to create a complete heat pump system. The compact form factor accommodates installations where wall-mounted or cassette units are impractical, making it suitable for retrofits, new construction, and spaces requiring distributed airflow through multiple supply registers.

Key Features

• R32 refrigerant with lower global warming potential and recyclability
• Inverter-driven compressor technology for precise capacity modulation
• WiFi connectivity with smart app control for remote operation
• Multiple operating modes: Cool, Heat, Dry, Fan, Auto, Turbo, Quiet, and Sleep
• Follow Me temperature sensing via wireless remote
• Timer ON/OFF programming and child lock functionality

Compatibility

The BRV-P18DT230VI is designed for use within the BRAVO ROMA mini split ecosystem. This indoor unit connects to compatible BRAVO ROMA single-zone or multi-zone outdoor condensers using standard 1/4" liquid and 3/8" gas refrigerant piping. Communication wiring requires AWG 18-4 conductor. Verify outdoor unit compatibility and total system capacity matching before installation.

Installation Notes

Install the slim duct unit in an accessible location allowing for service access and condensate drainage. Maintain minimum clearances per manufacturer specifications for return air intake and supply duct connections. Refrigerant lines require proper insulation and flare nut torque to prevent leaks. Electrical work must comply with NEC and local codes; qualified HVAC technicians should perform all refrigerant handling and system commissioning.

Technical Specifications

• Capacity: 18,000 BTU
• Power Supply: 208-230V, 1Ph, 60Hz
• Voltage Range: 165-264V
• Refrigerant Type: R32
• Refrigerant Piping: 1/4" liquid / 3/8" gas
• Communication Wiring: AWG 18-4
• System Type: Multi-zone compatible indoor unit

Standard Information

• Brand: BRAVO ROMA
• MPN: BRV-P18DT230VI
• MasterSKU: d31b86a7-f6ca-4778-93e1-cea0c853b962
• Country of Origin: Not specified in available documentation
