Bravo BRV-M24FC-230VI Ceiling Cassette Indoor Unit 24K BTU Multi-Zone-Compatible

Product Description

The BRAVO BRV-M24FC-230VI is a 24,000 BTU ceiling cassette indoor unit engineered for commercial and residential multi-zone ductless mini-split systems. Designed for discreet installation in drop ceilings or suspended ceiling applications, this unit delivers 360-degree airflow distribution through four-way discharge louvers for uniform temperature control across large open spaces. The low-profile chassis fits standard ceiling grids, making it ideal for offices, retail environments, hospitality settings, and residential basements where wall-mounted equipment is impractical or undesirable.

This indoor unit pairs with BRAVO Milano series multi-zone outdoor condensers using R32 refrigerant, supporting inverter-driven variable capacity modulation for precise load matching and reduced energy consumption. The built-in condensate pump and drain pan simplify installation by eliminating external pump requirements, while the included decorative grill provides clean aesthetic integration with ceiling finishes.

Key Features

• Four-way ceiling cassette design with auto-swing louvers for 360° air distribution coverage
• Inverter-compatible operation for variable-speed capacity modulation and enhanced part-load efficiency
• Built-in condensate pump with drain connection for flexible drainage routing
• WiFi control capability with included remote controller for centralized system management
• Bluefin anti-corrosion coating on heat exchanger for extended service life in humid environments
• Multiple operating modes: Cooling, Heating, Dry/Dehumidify, Fan-Only, Turbo, Eco, and Sleep Mode

Compatibility

The BRV-M24FC-230VI is compatible with BRAVO Milano series multi-zone outdoor units (BRV-M24-230VO, BRV-M30-230VO, BRV-M36-230VO, BRV-M42-230VO) operating on 208-230V single-phase power. This indoor unit requires 1/4-inch liquid line and 1/2-inch suction line refrigerant connections. System combination must not exceed the outdoor unit's maximum connected capacity. Confirm outdoor unit refrigerant precharge and piping length allowances with manufacturer submittal data prior to installation.

Installation Notes

Install unit with minimum service clearance per local code and manufacturer requirements. Verify structural support for unit weight plus condensate load. Connect low-voltage communication wiring between indoor and outdoor units per manufacturer wiring diagrams. Ensure level installation for proper condensate drainage. Coordinate ceiling grid modifications and structural support with appropriate trades.

What's Included

• BRV-M24FC-230VI ceiling cassette indoor unit
• Decorative grille/face panel
• Wireless remote controller with wall-mount holder
• Installation hardware and mounting brackets
• Owner's manual and installation instructions

Specifications

• Cooling Capacity: 24,000 BTU/hr
• Heating Capacity: 26,000 BTU/hr (varies by outdoor unit)
• Power Supply: 208-230V, 1-Phase, 60Hz (outdoor unit powered)
• Refrigerant Lines: 1/4" liquid, 1/2" suction
• Drain Connection: Built-in condensate pump with drain outlet
• Airflow: 4-way discharge with auto-swing louvers
• Sound Level: Low noise operation
• Dimensions (WxDxH): Approximately 33.1" x 33.1" x 9.25" (chassis)
• Weight: Varies by configuration
• Refrigerant Type: R32
