Brasscraft PR-14 Series Straight Supply Stop Valve 1/2 x 3/8 in.

Product Description

The Brasscraft PR-14 Series straight valve controls water flow to household plumbing fixtures. The valve features a machined, one-piece body for strength and durability. Compatible with CPVC tubing, it's designed for potable water distribution systems. Multi-turn operation allows water flow control with a few turns of the handle.

• Machined, one-piece body construction for strength, durability and long-lasting performance
• Compatible with CPVC tubing
• Multi-turn operation means water flow control with only a few turns of the handle

Product Highlights

Durable and reliable, this straight valve is ideal for controlling water flow to faucets, toilets, and other plumbing fixtures.

Product Information

Standard Information

• Brand: Brasscraft
• Manufacturer Part Number: PR-14
• Country of Origin: Domestic

Technical Specifications

• ANSI: ANSI 372, ANSI 61
• ASME: ASME A112.18.1
• CSA Certified: CSA B125.1
• Collection: PR14 Series
• Color Finish Category: Chromes
• Color Finish Name: Chrome
• End Connection 1: Socket Weld
• End Connection 2: Compression
• End Connections: Socket Weld x Compression
• Handle Material: Lexan
• Handle Type: Knurled
• IAPMO Listed: Yes
• Lead Law Compliance Level: Lead Law Compliant and Certified
• Lead Law Compliant: Yes
• Length: 2-3/5
• Material: Brass, Plastic
• Material Type: Lexan
• Maximum Temperature: 140
• Minimum Temperature: 40
• NSF: NSF 372, NSF 61
• NSF Certified: Yes
• Number of Handles: Single Handle
• Origin: Domestic
• Pressure - Maximum: 125 psi
• Recommended Valve Application: Potable Water
• Temperature Range: 40 to 160 Deg F
• UL Listed: No
• Valve Body Material: Brass
• Valve Body Style: 1 piece
• Valve Operator: Oval Knurled Handle
• Valve Size: 1/2 in x 3/8 in
• Valve Type: Straight Supply Stop Valve
• Material/Finish: Brass/Chrome
• Inlet: 1/2 in. Nom CPVC
• Outlet: 3/8 in. O.D. Comp
• Application: Controls water flow to household plumbing fixtures
• Brand: Brasscraft
• MPN: PR14R
• UPC: Does not apply
