Brasscraft KTCR14X C1 1/2 in. Nom Comp x 3/8 in. O.D. Comp

Product Description

The BrassCraft KTCR14X C1 1/2 in. Nom Comp Inlet x 3/8 in. OD Comp Outlet 1/4-Turn Straight Ball Stop controls water flow to household plumbing fixtures such as faucets, toilets, dishwashers, icemakers, and washing machines. With a 90-degree turn of the valve handle, the flow of water leading to the plumbing fixture can be stopped for maintenance and repair. Machined brass body provides strength, durability and long-lasting performance.

• Machined brass body provides strength, durability and long-lasting performance
• 1/2 in. Nom Comp Inlet x 3/8 in. OD Comp Outlet
• Compatible with copper pipe

Product Highlights

This straight ball stop is for use in potable and recirculating water systems. It features a precision-machined brass ball for smooth operation and is 100% leak tested.

Product Information

Standard Information

• Brand: BRASSCRAFT
• Manufacturer Part Number: KTCR14X C1
• Country of Origin: USA

Technical Specifications

• Inlet: 1/2 in. Nom Comp
• Outlet: 3/8 in. O.D. Comp
• Type: Straight Ball Stop
• Material: Brass
• Finish: Chrome
• Temperature Rating: 40 to 180 deg F
• Pressure Rating: 125 psi maximum
• Series: KT™
• Nominal Size: 1/2 x 3/8 in
• End Style: Compression End Style
• Media: Water
• Body Material: Brass Body
• Trim Material: Brass Trim
• Softgoods: Rubber Stem O-Ring/PTFE Seat Softgoods
• Handle: Metal
