Brasscraft G23301 C1 Angle Valve 1/2 in. FIP x 7/16 in. & 1/2 in. OD Slip-Joint

Product Description

The BrassCraft G23301 C1 is a 1/2 inch FIP inlet x 7/16 inch & 1/2 inch OD slip-joint angle valve. This valve controls the flow of water to plumbing fixtures in a home. It is designed for use where the water pipe enters the room from the wall, allowing for maintenance without shutting off water to the entire system.

• One-piece brass body offers durability.
• 1/4-turn mechanism allows smooth operation.
• Leak tested to ensure performance.

Product Highlights

This angle valve features a one-piece brass construction. It has a quarter-turn handle and is leak tested, ensuring reliable operation. It is suitable for indoor use with a temperature range of forty to one hundred sixty degrees Fahrenheit and a pressure rating of up to one hundred twenty-five psi.

Product Information

Standard Information

• Manufacturer: Trumbull Industries
• Part Number: G23301 C1

Technical Specifications

• Inlet: 1/2 inch FIP
• Outlet: 7/16 inch & 1/2 inch O.D. Slip-Joint
• Maximum Temperature: 160
• Minimum Temperature: 40
• Pressure - Maximum: 125 psi
• Valve Type: Angle Supply Stop Valve
• Valve Size: 1/2 inch x 7/16 inch
• Handle Material: ABS
• Lead Law Compliance: Yes
• Measurement System: inch
