Bramec 13830 10 Gauge Stranded Copper Wire 500 Ft

Product Description

The BRAMEC 13830 is a 10-gauge white stranded copper wire supplied on a 500-foot spool. Stranded construction makes this wire flexible and easier to route through conduit, panels, and equipment enclosures compared to solid conductors. The white insulation jacket provides standard color-coding for neutral or secondary conductors in low-voltage and line-voltage wiring applications. This wire is a staple for licensed electricians and HVAC technicians working on branch circuits, equipment connections, and control wiring installations where a 10-gauge conductor is specified.

This wire is suited for residential and light commercial electrical and HVAC wiring tasks. Common applications include branch circuit runs to HVAC equipment, panel wiring, and general-purpose conductor work where a 10-gauge stranded copper wire is called for. The 500-foot spool length supports larger jobs and reduces the need for splices on longer runs.

Key Features

• 10-gauge stranded copper construction for flexibility during installation
• White insulation jacket for standard conductor color identification
• 500-foot spool reduces splices on longer wiring runs
• Stranded design allows easier routing through conduit and tight enclosures

Compatibility

Designed for use in general electrical and HVAC wiring applications requiring a 10-gauge stranded copper conductor.

Installation Notes

Installation should be performed by a licensed electrician or qualified HVAC technician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out all circuits before making connections. Use wire connectors, lugs, or terminals rated for 10-gauge stranded copper. Verify conductor ampacity requirements against the load and conduit fill calculations before pulling wire.

Technical Specifications

• Wire Gauge: 10 AWG
• Conductor Type: Stranded Copper
• Insulation Color: White
• Spool Length: 500 feet
• Box Quantity: 1

Standard Information

• Brand: BRAMEC
• Manufacturer Part Number: 13830
