Bramec 13174 Liquidtight Conduit Connector 45 Degree 1/2 in

Product Description

The BRAMEC 13174 is a 45-degree elbow liquidtight conduit connector designed for use with non-metallic liquidtight flexible conduit in trade size 1/2 inch. Constructed from nylon, this fitting provides a secure, moisture-resistant termination point where conduit meets an enclosure or junction box. The 45-degree angle makes it well suited for routing conduit in tight spaces or at offset angles without stressing the conduit body. Electricians use this type of connector on HVAC equipment wiring, pump panels, outdoor enclosures, and other installations where moisture or liquid exposure is a concern.

This connector is intended for use on non-metallic liquidtight flexible conduit in trade size 1/2 inch. Common applications include low-voltage control wiring on HVAC systems, pool and spa equipment wiring, irrigation controllers, and any installation where flexible conduit must terminate at an angled entry point. The nylon construction resists corrosion, making it appropriate for damp or wet-rated locations. Packaged 50 per pack, it is practical for service vehicles and jobsite stock.

Key Features

• 45-degree elbow angle for angled conduit entry and tight-space routing
• Nylon construction resists corrosion in damp and wet locations
• Trade size 1/2 inch for use with standard 1/2 inch non-metallic liquidtight conduit
• UL listed for code-compliant installations
• Packaged 50 per pack for efficient stock replenishment

Compatibility

Designed for use on non-metallic liquidtight flexible conduit in trade size 1/2 inch.

Installation Notes

Installation is performed by licensed electricians in accordance with applicable NEC requirements for liquidtight flexible conduit systems. De-energize the circuit and verify zero voltage before beginning work on any enclosure or panel. Ensure the conduit is fully seated into the connector body and the locknut is tightened securely to maintain the liquidtight seal. Do not over-torque nylon fittings, as the material can crack under excessive force.

Technical Specifications

• Trade Size: 1/2 inch
• Type: 45 Degree Elbow
• Material: Nylon
• Used On: Non-Metallic Liquidtight Conduit
• Approval: UL Listed
• Standard Package Quantity: 50 per pack

Standard Information

• Brand: BRAMEC
• Manufacturer Part Number: 13174
