Bramec 13160 Ac Disconnect Switch 60A 3-phase Fused Nema 3R

Product Description

The BRAMEC 13160 is a fused air conditioner disconnect switch rated for 60 amps in 3-phase applications. Housed in a NEMA 3R enclosure, it provides a code-compliant means of disconnecting power to commercial or residential air conditioning equipment. The NEMA 3R rating makes it suitable for outdoor installation, offering protection against rain, sleet, and external ice formation. Fuse provisions allow for overcurrent protection at the equipment level. Licensed electricians install this type of disconnect as required by the NEC for HVAC equipment served by a dedicated branch circuit.

This disconnect switch is suited for 3-phase air conditioning systems where a weatherproof, fused shutoff is required within sight of the equipment. Typical applications include rooftop units, packaged systems, and large split-system condensers operating on 3-phase power. It is appropriate for both new installations and replacement of aging or non-compliant disconnect hardware on commercial and light-industrial equipment.

Key Features

• 60-amp current rating supports heavy-duty 3-phase AC equipment
• Fused design provides integrated overcurrent protection at the disconnect point
• NEMA 3R enclosure rated for outdoor use, resistant to rain, sleet, and ice
• 3-phase configuration for commercial and light-industrial air conditioning systems
• Provides NEC-required visible means of disconnect for HVAC equipment

Compatibility

Designed as an OEM-style replacement or new-installation disconnect for 3-phase air conditioning equipment requiring a fused, NEMA 3R-rated shutoff switch.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. Verify that all upstream power is de-energized and locked out before beginning any wiring work. The disconnect must be mounted within sight of the equipment it serves, as required by NEC Article 440. Do not exceed the 60-amp current rating of the device.

Technical Specifications

• Current Rating: 60 amps
• Phase: 3-phase
• Fuse Provision: Fused
• Enclosure Type: NEMA 3R
• Switch Type: Air Conditioner Disconnect Switch

Standard Information

• Brand: BRAMEC
• Manufacturer Part Number: 13160
