Bradley s19274jw Recessed Plumbed Eyewash Station

Product Description

The BRADLEY s19274jw is a fully recessed, wall-mounted plumbed eyewash station designed for general-purpose emergency eye irrigation. The unit connects directly to a potable water supply via a 1/2 inch female NPT inlet and delivers water through two chrome-plated brass spray heads, each 1 inch in diameter. Activation is accomplished by a swing-down handle, also chrome-plated brass, which allows single-motion operation during an emergency. The ceramic valve provides reliable shutoff and long service life. This station is intended for installation by licensed plumbers in commercial, industrial, or institutional facilities where ANSI-compliant emergency eyewash access is required.

The s19274jw is suited for environments where wall space is limited and a flush-mounted appearance is preferred. The fully recessed mounting style means the unit sits within the wall cavity, minimizing protrusion into the work area. At 9.5 inches in height and depth and approximately 7.92 inches in width, the station fits within a standard wall rough-in. The unit ships fully assembled and includes an inspection tag and a universal identification sign, supporting compliance documentation and station visibility requirements under ANSI emergency eyewash standards.

Key Features

• Fully recessed, wall-mount installation minimizes protrusion into the work area
• Swing-down activation handle allows single-motion emergency operation
• Two 1 inch chrome-plated brass spray heads provide bilateral eye coverage
• 1/2 inch female NPT inlet compatible with standard plumbing supply lines
• Ceramic valve construction for durable, long-cycle shutoff performance
• Ships fully assembled with inspection tag and universal identification sign included
• Meets ANSI standards and is UL Listed

Compatibility

Designed as an OEM-style fully recessed plumbed eyewash station for wall installations requiring a 1/2 inch NPT water supply connection in general-purpose environments.

Installation Notes

Installation should be performed by a licensed plumber in accordance with applicable local plumbing codes and ANSI Z358.1 emergency eyewash requirements. Shut off the water supply to the feed line before roughing in the inlet connection. The 1/2 inch female NPT inlet requires a male NPT supply fitting — use appropriate thread sealant and verify no cross-threading before pressurizing. After installation, flush the unit per ANSI guidelines before placing it in service, and record the date on the included inspection tag.

Technical Specifications

• Mounting Style: Fully Recessed
• Mount Type: Wall
• Installation Type: Plumbed
• Coverage: Eyes
• Activation: Swing Down
• Number of Spray Heads: 2
• Spray Head Diameter: 1 inch
• Spray Head Material: Chrome-Plated Brass
• Pipe Material: Chrome-Plated Brass
• Handle Material: Chrome-Plated Brass
• Valve Material: Ceramic
• Inlet Pipe Size: 1/2 inch
• Inlet Pipe Thread Type: NPT
• Inlet Pipe Gender: Female
• Outlet Pipe Thread Type: NPT
• Mount Hole Diameter: 1/2 inch
• Height: 9.5 inches
• Width: 7.92 inches
• Depth: 9.5 inches
• Color: Silver
• Bowl Style: No Bowl
• Includes: Inspection Tag, Universal Identification Sign
• Assembly: Assembled
• Standards: ANSI, UL Listed
• Barrier Free: No
• Hazardous Location Rating: Not Rated
• Includes Foot Pedal: No
• Environment: General Purpose
• UNSPSC: 46181810
• Country of Origin: Varies (subject to change)

Standard Information

• Brand: BRADLEY
• Manufacturer Part Number: s19274jw
