Bradley S19-120 Horizontal Drench Shower Pull Rod

Product Description

The BRADLEY S19-120 is a plumbed horizontal-mount drench shower designed for emergency eyewash and shower stations in industrial, laboratory, and commercial environments. It delivers a high-volume water flow of 22.0 GPM through a plastic shower head measuring 3.1 inches in diameter, activated by a pull rod mechanism for fast, hands-free operation. The supply pipe is galvanized steel for corrosion resistance in demanding service environments. This unit meets ANSI Z358.1 requirements for emergency shower equipment. Installation is typically performed by licensed plumbers or safety equipment technicians as part of a code-compliant emergency response system.

The S19-120 is suited for horizontal pipe entry configurations where overhead or vertical mounting is not feasible. It is commonly installed in manufacturing facilities, chemical handling areas, laboratories, and other workplaces requiring ANSI Z358.1-compliant emergency shower coverage. The pull rod activation allows a worker to initiate flow immediately without fine motor control, which is critical during a chemical exposure incident. Overall installed height is 25.5 inches and overall length is 15.75 inches, making it appropriate for installations with limited vertical clearance.

Key Features

• Horizontal mount configuration for flexible installation in space-constrained areas
• Pull rod activation for immediate, hands-free emergency operation
• 22.0 GPM maximum flow rate meets ANSI Z358.1 emergency shower requirements
• Galvanized steel pipe construction for corrosion resistance
• Plastic shower head and head material for chemical compatibility in washdown environments
• Compact footprint: 25.5 inches overall height, 15.75 inches overall length

Compatibility

Designed as an OEM-style replacement or new-installation drench shower head assembly for horizontal-mount emergency shower systems requiring ANSI Z358.1 compliance.

Installation Notes

Installation should be performed by a licensed plumber in accordance with applicable local plumbing codes and ANSI Z358.1 positioning requirements, including the specified height range above the walking surface. Shut off the water supply to the branch line before making any pipe connections. Do not overtighten plastic shower head fittings against galvanized steel pipe threads. After installation, perform a full flow test and verify activation force and water distribution pattern meet ANSI Z358.1 standards before putting the unit into service.
