Boston Gear NJ120B Cast Iron Spur Gear 6 DP 14 1/2 PA 120 Teeth

Product Description

The Boston Gear NJ120B is a cast iron spur gear designed for effective power transmission between parallel shafts. This gear features a diametral pitch of six and has one hundred twenty teeth. It is suitable for various mechanical applications.

• Designed for parallel shaft applications.
• Uses cast iron material for durability.
• Suitable for both industrial and mechanical uses.

Product Highlights

This spur gear is part of a range of products that include options for different bore sizes and keyways, ensuring compatibility with various systems.

Product Information

Standard Information

• Brand: Boston Gear
• MPN: NJ120B

Technical Specifications

• Material: Cast Iron
• Outside Diameter: 20.33 inches
• Pitch Diameter: 20 inches
• Number of Teeth: 120
• Bore Size: 1.250 inches
• Hub Diameter: 3.5 inches
• Weight: 38.901 lbs
• Pressure Angle: 14.5 degrees
• Diametral Pitch: 6
