Boston Gear H3232 Steel Spur Gear 32 DP 14.5° PA 32 Teeth

Product Description

Boston Gear H3232 Steel Spur Gear is designed for motion and power transmission between parallel shafts. This gear features a total of thirty-two teeth and is ideal for applications requiring effective power delivery. It is constructed from durable steel and has a pitch diameter of one inch, making it suitable for a variety of mechanical setups.

• 32 diametral pitch for efficient power transmission
• Compatible with various bore sizes, keyways, and setscrews
• Manufactured with a pressure angle of fourteen and a half degrees

Product Highlights

This spur gear provides low backlash and quiet operation. It is an effective choice for use in various applications, ensuring reliable performance in mechanical systems.

Product Information

Standard Information

• Brand: Boston Gear
• MPN: H3232

Technical Specifications

• Torque at 1800 RPM: 10.7 lb/in
• Number of Teeth: 32
• Bore Size: 0.3125 in
• Diametral Pitch: 32
• Pressure Angle: 14.5 degrees
• Outside Diameter: 1.0625 in
• Material: Steel
• Weight: 0.081 lb
