Bosch 8733980520 36000 Btu 4-zone Mini-split System

Product Description

The BOSCH 8733980520 is a 36,000 BTU 4-zone ductless mini-split system designed for multi-room heating and cooling in residential and light commercial applications. The kit includes two indoor air handler units and one outdoor condenser unit, pre-matched for optimized performance. Each indoor unit connects to the outdoor unit via 25-foot linesets included in the package. This system is intended for installation by licensed HVAC technicians and is well suited for homes or buildings where zoned comfort control is required without the need for ductwork.

This 4-zone configuration supports independent temperature control across multiple spaces simultaneously. The system ships as a complete kit with all major components — two indoor units (IDU) and one outdoor unit (ODU) — reducing sourcing time on multi-zone jobs. The grille is included with the indoor units. This system targets residential new construction, retrofit applications, and light commercial spaces where duct installation is impractical or cost-prohibitive.

Key Features

• 36,000 BTU total system capacity for multi-zone coverage
• 4-zone configuration with two indoor air handlers and one matched outdoor unit
• 25-foot lineset length supports standard installation distances
• Grille included with indoor units — no separate grille sourcing required
• Kit ships as a complete matched system: IDU x2 and ODU x1
• Net kit weight of 222.61 pounds; gross kit weight of 286.54 pounds

Compatibility

Kit includes indoor unit 8733962682 (x1), indoor unit 8733962703 (x1), and outdoor unit 8733962692 (x1), factory-matched as a complete 4-zone ductless system assembly.

Installation Notes

Installation must be performed by a licensed HVAC technician familiar with ductless mini-split systems. Power down all circuits before connecting or servicing any system components. Follow all local mechanical and electrical codes, including NEC requirements for dedicated circuits and disconnect placement. Do not exceed the specified lineset length without consulting manufacturer guidelines, as refrigerant charge and system performance may be affected.

Technical Specifications

• System Capacity: 36,000 BTU/h
• Number of Zones: 4
• Lineset Length: 25 feet
• Kit Net Weight: 222.61 pounds
• Kit Gross Weight: 286.54 pounds
• Indoor Unit 1 Part Number: 8733962682
• Indoor Unit 2 Part Number: 8733962703
• Outdoor Unit Part Number: 8733962692
• UPC: 52575024202

Standard Information

• Brand: BOSCH
• Manufacturer Part Number: 8733980520
