Bosch 8733980517 Mini Split 12000 Btu 4-zone Cassette 230V

Product Description

The BOSCH 8733980517 is a 12,000 BTU multi-zone mini split system configured for four-zone cassette-style indoor units, operating on 230 volts. The kit includes two indoor cassette units and one outdoor condensing unit, along with a grille and 25-foot lineset. This system is designed for residential and light commercial applications where ceiling cassette distribution is preferred. Licensed HVAC technicians install this type of system as a ductless solution for multi-room or multi-zone comfort control.

This kit is suited for installations requiring ceiling-recessed air distribution across up to four zones without a line set separator. The 230-volt configuration is standard for residential mini split installations. The included grille and pre-cut 25-foot lineset reduce job-site sourcing and simplify staging. Typical applications include office suites, retail spaces, multi-room residential builds, and retrofit projects where duct runs are impractical.

Key Features

• 12,000 BTU capacity for multi-zone ductless cooling and heating
• Four-zone cassette indoor unit configuration for ceiling-recessed air distribution
• 230-volt operation compatible with standard residential and light commercial electrical service
• Includes two indoor cassette units (IDU 8733962717 and IDU 8733962708) and one outdoor unit (ODU 8733962685)
• Grille and 25-foot lineset included, reducing field procurement
• No line set separator required in this configuration

Compatibility

This kit includes indoor units 8733962717 and 8733962708 paired with outdoor unit 8733962685. No additional compatibility data was provided in the product input; consult BOSCH documentation to confirm compatibility with other components or control accessories.

Installation Notes

Installation must be performed by a licensed HVAC technician holding an EPA Section 608 certification for refrigerant handling. Power down and lock out the electrical circuit before connecting any components. Ceiling cassette units require structural support and proper condensate drainage planning prior to mounting. Follow all local mechanical and electrical codes during refrigerant line routing, electrical connection, and commissioning.

Technical Specifications

• Capacity: 12,000 BTU/h
• Voltage: 230 volts
• Zone Count: 4 zones
• Lineset Length Included: 25 feet
• Indoor Unit 1 Part Number: 8733962717
• Indoor Unit 2 Part Number: 8733962708
• Outdoor Unit Part Number: 8733962685
• Kit Net Weight: 103.39 pounds
• Kit Gross Weight: 154.05 pounds
• UPC: 52575024172

Standard Information

• Brand: BOSCH
• Manufacturer Part Number: 8733980517
