Bosch 8733980515 24000 Btu 4-zone Mini Split System

Product Description

The BOSCH 8733980515 is a 24,000 BTU four-zone ductless mini split system designed for residential and light commercial heating and cooling applications. This Generation 4 kit includes two indoor air handling units, one outdoor condensing unit, and a 25-foot line set, making it a complete package for multi-zone climate control installations. The system ships with grille accessories included. With a net kit weight of 195.34 pounds, this is a substantial multi-component assembly intended for professional installation by licensed HVAC technicians.

This system is suited for installations requiring simultaneous comfort control across up to four zones, such as multi-room residential builds, additions, or retrofits where ductwork is not practical. The 25-foot line set included in the kit supports typical wall-penetration routing between indoor and outdoor units. The Generation 4 platform is appropriate for both new construction and replacement projects in residential and light commercial settings.

Key Features

• 24,000 BTU total system capacity for multi-zone heating and cooling
• Four-zone configuration with two indoor units and one outdoor condensing unit
• Complete kit includes indoor units, outdoor unit, 25-foot line set, and grille accessories
• Generation 4 design for updated system performance and compatibility
• Kit net weight of 195.34 pounds — plan for multi-person handling and rigging during installation

Compatibility

This kit includes indoor unit 8733962681, indoor unit 8733962703, outdoor unit 8733962687, and line set 8733951015 as matched components. Designed as a factory-matched BOSCH mini split system kit; substitution of individual components should be verified against BOSCH engineering documentation before proceeding.

Installation Notes

Installation must be performed by a licensed HVAC technician with EPA Section 608 certification for refrigerant handling. Power down all circuits at the breaker panel before making any electrical connections. Follow all applicable local mechanical and electrical codes, including NEC requirements for disconnect placement and circuit sizing. Do not mix matched system components with unverified third-party units without confirming compatibility with the manufacturer.

Technical Specifications

• System Capacity: 24,000 BTU/h
• Number of Zones: 4
• Included Line Set Length: 25 feet
• Generation: G4
• Kit Net Weight: 195.34 pounds
• Kit Gross Weight: 259 pounds
• UPC: 52575024158
• Indoor Unit 1 Part Number: 8733962681
• Indoor Unit 2 Part Number: 8733962703
• Outdoor Unit Part Number: 8733962687
• Line Set Part Number: 8733951015

Standard Information

• Brand: BOSCH
• Manufacturer Part Number: 8733980515
