Bosch 8733980460 Mini Split Heat Pump Kit 12000 Btu/h 230V

Product Description

The BOSCH 8733980460 is a single-zone mini split heat pump kit rated at 12000 BTU/h, operating on 230 volts. The kit includes one indoor unit (IDU) and one outdoor unit (ODU), providing a complete system ready for installation. It achieves a SEER2 rating of 25.5 and an EER2 of 13.0, placing it among the more efficient options in its class. The HSPF2 rating of 10.6 and a COP at 47 degrees F of 3.9 confirm solid heating performance in mild to moderate climates. This system carries Energy Star certification. It is installed by licensed HVAC technicians in residential and light commercial applications.

This kit is designed for single-zone heating and cooling applications where a ducted system is not practical or desired. The self-contained indoor and outdoor unit pairing simplifies the job for the installing contractor. Typical applications include room additions, garage conversions, server rooms, and supplemental conditioning in residential or small commercial buildings. The system runs on 230-volt power, which is standard for mini split installations in North America. No line set is included with this kit.

Key Features

• 12000 BTU/h cooling capacity for single-zone coverage
• 25.5 SEER2 efficiency rating meets current federal standards with significant margin
• 10.6 HSPF2 heating efficiency for year-round operation
• COP of 3.9 at 47 degrees F for effective cold-weather heating
• Energy Star certified for qualifying rebate and incentive programs
• Complete kit includes matched IDU (8733962673) and ODU (8733962685)

Compatibility

This kit is a matched system pairing BOSCH indoor unit 8733962673 with outdoor unit 8733962685. It is intended for use as a complete single-zone mini split installation and is not designed for multi-zone configurations.

Installation Notes

Installation must be performed by a licensed HVAC technician in accordance with local mechanical codes and the manufacturer instructions. Shut off and lock out all electrical power before making any electrical connections. Refrigerant handling requires EPA Section 608 certification. Verify that the electrical supply circuit is sized and protected correctly for a 230-volt mini split system before energizing.

Technical Specifications

• Cooling Capacity: 12000 BTU/h
• Voltage: 230 volts
• SEER2: 25.5
• EER2: 13.0
• HSPF2: 10.6
• COP at 47 degrees F: 3.9
• Energy Star Certified: Yes
• AHRI Certified: Yes
• Kit Net Weight: 85.1 pounds
• Kit Gross Weight: 132 pounds
• UPC: 52575023601

Standard Information

• Brand: BOSCH
• Manufacturer Part Number: 8733980460
