Bosch 8733980395 Mini Split System Kit 12000 Btu/h SEER2 25.5

Product Description

The BOSCH 8733980395 is a single-zone mini split system kit rated at 12000 BTU/h, designed for residential and light-commercial heating and cooling applications. Operating at 230 volts, this kit delivers a SEER2 rating of 25.5 and an HSPF2 of 10.6, meeting Energy Star requirements. It ships as a complete package including an indoor unit, outdoor unit, and a 25-foot line set, reducing staging time on the job. Licensed HVAC technicians handle installation, which involves refrigerant line connection, low-voltage wiring, and commissioning. The kit net weight is 94.95 pounds.

This system is suited for single-room or single-zone conditioning in residential homes, apartments, additions, or small commercial spaces where ducted systems are not practical. The 25-foot pre-flared or flareable line set accommodates typical wall penetration distances without requiring additional lineset. The kit format simplifies procurement, ensuring the indoor unit, outdoor unit, and line set are matched components sourced together. HVAC contractors and mechanical installers are the primary trades for this equipment.

Key Features

• Complete single-zone kit: indoor unit (8733962673), outdoor unit (8733962685), and line set (8733951011) included
• 12000 BTU/h capacity for single-zone heating and cooling
• SEER2 25.5 efficiency rating meets current DOE testing standards
• HSPF2 10.6 heating efficiency with COP of 3.9 at 47 degrees F
• Energy Star certified
• 230-volt operation compatible with standard single-phase residential electrical service

Compatibility

This kit contains matched components: indoor unit 8733962673, outdoor unit 8733962685, and line set 8733951011. These components are factory-matched for this single-zone configuration and should not be substituted with unverified alternatives.

Installation Notes

Installation must be performed by a licensed HVAC technician holding an EPA Section 608 certification due to the refrigerant handling involved. Disconnect and lock out all electrical power before working on the system. The line set connection and refrigerant circuit must be pressure-tested and evacuated to a deep vacuum before charging or releasing the factory refrigerant charge. Follow local mechanical and electrical codes, including NEC requirements for disconnect placement and circuit protection sizing.

Technical Specifications

• Capacity: 12000 BTU/h
• Voltage: 230 volts
• SEER2: 25.5
• EER2: 13.0
• HSPF2: 10.6
• COP at 47 degrees F: 3.9
• Energy Star Certified: Yes
• AHRI Rated: Yes
• Line Set Length: 25 feet
• Kit Net Weight: 94.95 pounds
• Kit Gross Weight: 141.85 pounds
• UPC: 52575022956

Standard Information

• Brand: BOSCH
• Manufacturer Part Number: 8733980395
