Bonomi North America VB190M Electric Actuator

Product Description

The BONOMI NORTH AMERICA VB190M electric actuator features an aluminum housing with IP68 protection, handwheel latching manual override, and visual position indication. It includes 2 limit switches for remote open and closed position indication, an electronic torque limiter, and an internal anti-condensation heater. The unit has 2 x M20 x 1.5 conduit entries and ISO F07 / F10 mounting with a 22 MM star drive.

• Aluminum housing with IP68 protection
• Handwheel latching manual override
• Visual position indication

Product Highlights

Durable electric actuator with manual override, position indication, and environmental protection.

Product Information

Standard Information

• Brand: BONOMI NORTH AMERICA
• Manufacturer Part Number: VB190M

Technical Specifications

• Mounting: ISO F07 / F10
• Drive: 22 MM star drive
• Housing: Aluminum
• Protection: IP68
• Manual Override: Handwheel latching manual override
• Position Indication: Visual position indication
• Limit Switches: 2 x Mechanical limit switches for remote open/closed position feedback
• Torque Limiter: Electronic torque limiter
• Heater: Anti-condensation heater
• Conduit Entries: 2 x M20 x 1.5
• Voltage Rating: 100 - 240 VAC
• Series/Model: Model VB190M
• Body Material: Aluminum
• Power Rating: 60 - 72 VA
• Amperage Rating: 0.6 - 0.3 A
• Industry Standards: ISO F03/F05/ F07, ISO 5211
• Enclosure: IP67
• Temperature Rating: -20 To 55 DEG C
• Length: 270 MM
• Width: 266 MM
• Height: 313 MM
• Additional Specifications: Frequency Rating: 50/60 HZ
• Brand: Bonomi
• Actuator Action: ON/OFF ACTUATOR
• Output Torque: 1680 in-Lbs
• Actuator Housing Material: Aluminum die cast
