Bonomi North America DA85 Double Acting Actuator

Product Description

The BONOMI NORTH AMERICA DA85 is a double acting actuator. This pneumatic actuator features an extruded aluminum body and operates at 141 Nm at 8 Bar. It adheres to industry standards ATEX II 2GD T6, ISO 5211 - DIN 3337.

• Extruded aluminum double acting pneumatic actuator 141 NM at 8 BAR
• Pressure Rating: 40 - 115 PSI
• Temperature Rating: Standard: -4 To 185 DEG F, High: -4 To 302 DEG F, Low: -40 To 185 DEG F

Product Highlights

The BONOMI NORTH AMERICA DA85 double acting actuator is designed for robust performance and adherence to industry standards.

Product Information

Standard Information

• Brand: BONOMI NORTH AMERICA
• Manufacturer Part Number: DA85

Technical Specifications

• Item Name: Pneumatic Actuator
• Type: Double Acting
• Series/Model: Model DA85
• Pressure Rating: 40 - 115 PSI
• Output Torque: 141 Nm At 8 Bar
• Body Material: Extruded Aluminum
• Industry Standards: ATEX II 2GD T6, ISO 5211 - DIN 3337
• Temperature Rating: Standard: -4 To 185 DEG F, High: -4 To 302 DEG F, Low: -40 To 185 DEG F
• Length: 240.5 MM
• Width: 106 MM
• Height: 145 MM
• Additional Specifications: NBR O-Ring
• Action: Double Acting
• Brand: Bonomi
