Boneham AM00000069 Press Fit Drill Bushing Hm 19.5 in

Product Description

The BONEHAM AM00000069 is a press fit headless drill bushing manufactured to HM industry standards. It is installed directly into a jig plate without a head flange, making it well suited for flush-mount applications where clearance above the plate surface is required. The bushing features a 19.5-inch inside diameter and a steel construction designed to guide drill bits with precision during production or maintenance drilling operations. Machinists, toolmakers, and jig-and-fixture builders are the primary installers of this component.

This drill bushing is used in jig and fixture applications across manufacturing and metalworking environments. The headless press fit design allows the bushing to be pressed directly into a reamed hole in the jig body, where it remains fixed during drilling cycles. It is appropriate for both production and repair drilling setups where a renewable bushing is not required and a permanent installation is preferred.

Key Features

• HM industry bushing code for headless press fit style
• 19.5-inch inside diameter for precise drill guidance
• Steel construction for durability under repeated drilling cycles
• Flush-mount headless design suited for low-clearance jig plates
• Non-renewable fixed installation — no liner bushing required
• UNSPSC Code 31171603 for procurement classification

Compatibility

Designed as an OEM-style press fit headless drill bushing for use in steel jig plates and fixture bodies requiring an HM-coded bushing with a 19.5-inch inside diameter.

Installation Notes

Installation is performed by machinists or toolmakers using a hydraulic or arbor press to drive the bushing into a properly reamed hole in the jig plate. The receiving hole should be reamed to the appropriate tolerance for a press fit before installation. Power down any associated machinery before servicing or replacing jig components. Once pressed in, this bushing is not designed for removal and reuse.
