Bohn BCH0025LCACZA0000 condensing unit 2.5 hp 208-230/3/60

Product Description

The BOHN BCH0025LCACZA0000 is an air-cooled condensing unit featuring a 2.5 HP scroll compressor, designed for low temperature refrigeration applications. Operating on 208-230 VAC, three-phase, 60 Hz power, this unit is suitable for outdoor installation. It supports multiple refrigerants including R-404A, R-407A, R-407C, R-407F, R-448A, and R-449A, making it versatile for various refrigeration systems.

• Equipped with a 2.5 HP scroll compressor for efficient operation.
• Air-cooled design suitable for outdoor condenser location.
• Compatible with multiple refrigerants including R-404A, R-407A, R-407C, R-407F, R-448A, and R-449A.

Product Highlights

Versatile 2.5 HP air-cooled condensing unit for low temperature refrigeration.

Product Information

Standard Information

• Brand: BOHN
• Manufacturer Part Number: BCH0025LCACZA0000

Technical Specifications

• Unit of Measure: EA
• Amperage Range: 9-23 A
• Cooling Type: Air-Cooled
• Brand: Bohn
• Phase: Three
• Input Voltage: 208-230 VAC
• UL Listed: Yes
• Compressor Type: Scroll
• Frequency: 60 Hz
• Refrigerant Type: R-404A; R-407A; R-407C; R-407F; R-448A; R-449A
• Compressor Horsepower: 2 1/2 HP
• UL Recognized: No
• Energy Star Rated: No
• Condenser Location: Outdoor
• Condenser Motor Type: PSC (Permanent Split Capacitor)
• Liquid Line Size: 1/2" OD
• Rated Load Amps (RLA): 8.7 A
• Suction Line Size: 7/8" OD
• Minimum Circuit Ampacity (MCA): 15 A
• Connection Size: 1/2" x 1/8"
• Cooling Capacity: 9,690 Btuh
