Bmi Usa 6309 Brass 90 Degree Elbow 2 in Lead Free

Product Description

The BMI USA 6309 is a lead-free brass 90-degree elbow fitting designed for threaded pipe connections in plumbing and mechanical systems. Machined from solid brass, this elbow redirects flow at a right angle and is built to meet lead-free compliance requirements for potable water applications. At 2.14 pounds, it is a substantial, full-port fitting suited for 2-inch threaded connections. Licensed plumbers and pipefitters install this type of fitting during new construction, system modifications, and repair work where directional changes are required in a threaded piping run.

This elbow is appropriate for residential and commercial plumbing systems where a 2-inch threaded 90-degree change of direction is needed. Common applications include domestic water supply lines, hydronic heating systems, and general mechanical piping where brass fittings are specified. Its lead-free construction makes it suitable for potable water service in jurisdictions that enforce lead-free standards for plumbing components.

Key Features

• Lead-free brass construction meets potable water compliance requirements
• 90-degree elbow geometry for right-angle directional changes in threaded piping
• 2-inch size accommodates larger-diameter threaded pipe runs
• Solid brass material provides corrosion resistance and long service life in wet environments
• Threaded end connections for standard NPT pipe assembly

Compatibility

Designed as an OEM-style threaded brass elbow for use with 2-inch NPT-threaded piping systems in plumbing and mechanical applications.

Installation Notes

Installation should be performed by a licensed plumber in accordance with applicable local plumbing codes and the International Plumbing Code (IPC). Shut off the water supply and depressurize the system before removing or installing any fitting. Apply an appropriate thread sealant or PTFE tape to male threads before assembly, and tighten to snug-plus-hand-tight without over-torquing brass threads. Inspect for leaks after restoring system pressure.

Technical Specifications

• Material: Brass
• Size: 2 inches
• Configuration: 90 Degree Elbow
• Connection Type: Threaded
• Lead Free: Yes
• Weight: 2.14 pounds

Standard Information

• Brand: BMI USA
• Manufacturer Part Number: 6309
