Bmi Usa 6302 Brass 90 Degree Elbow 1/4 Inch Lead Free

Product Description

The BMI USA 6302 is a 1/4 inch lead-free brass 90 degree threaded elbow fitting designed for use in plumbing and mechanical piping systems. Constructed from solid brass, this elbow changes flow direction by 90 degrees in tight spaces where rigid pipe runs need to turn corners. The lead-free construction meets modern potable water standards, making it suitable for installations where water safety compliance is required. Licensed plumbers and pipefitters install this type of fitting in residential and light commercial systems during new construction and repair work.

This fitting is suited for 1/4 inch threaded pipe connections in plumbing, HVAC hydronic lines, and compressed air distribution. Its compact brass body handles standard service pressures found in residential and light commercial applications. The threaded ends accept standard NPT connections, allowing straightforward integration into existing threaded pipe assemblies without special tooling.

Key Features

• Lead-free brass construction meets potable water safety requirements
• 90 degree turn for direction changes in tight or confined piping runs
• 1/4 inch threaded connections for standard NPT pipe
• Lightweight at 0.1 pounds for easy handling in close-quarters installs
• Solid brass body resists corrosion in water and air service applications

Compatibility

Designed as an OEM-style replacement or new-installation fitting for 1/4 inch NPT threaded piping systems in plumbing, HVAC, and compressed air applications.

Installation Notes

Installation should be performed by a licensed plumber in accordance with local plumbing codes and IPC requirements. Shut off the water supply or depressurize the air line before disconnecting or installing any threaded fitting. Apply thread sealant tape or pipe dope to the male threads before assembly and tighten to a snug fit using an appropriately sized pipe wrench. Do not overtighten brass fittings, as the threads can crack or distort the body.

Technical Specifications

• Material: Brass
• Lead Free: Yes
• Connection Type: Threaded
• Angle: 90 Degrees
• Pipe Size: 1/4 inch
• Weight: 0.1 pounds

Standard Information

• Brand: BMI USA
• Manufacturer Part Number: 6302
